Specifications
Commodity:pipe equipment1. Pipe OD: 273-625mm
2. Thickness: 6-19mm
Commodity:pipe equipment for HG625mm
1. Specification of pipes and tubes:
Pipe OD: 273-625mm Thickness: 6-19mm
Square Tube: 200×1200mm- 450×450mm Thickness: 6-16mm
Rectangle Tube: 200×150mm-500×450mm Thickness: 6-16mm
Length: 6 -15m
Pipe Length Tolerance : ±3mm
2. Steel strip:
Material: Q 345 , low carbon steel, low alloy steel, mild steel
3. Forming Way:
ZTF technology for circle pipe,
Transform circle pipe into square and rectangle tube
Production Speed : 5-25 m/min
Direction : From left to right or decided by your side.
This line consists of uncoiler, pipe end opener, feeding machine, flattening mahcine, shear&welder, horizontal accumulator, forming&sizing mill, HF induction welder, cooling device, seam bead trimmer, annealer, pullingout device, cutoff machinery, conveyer table, hydro testing equipments, flattening test equipments, end facing&beveling machine, straightening testers, non-destructive testing equipments, measurement of size and dismension, weight mearsurer, mark painter, protective oil painter, collecting machine, packing machine.
