Help CenterERW219 H.F. Longitudinal Welded Pipe Making Machine
Related Products
Specifications
ERW219 pipe making machine can produceround square rectangular and profiled pipes with
OD 76-219mm thickness 2-6.5mm
Commodity: pipe making machine
ERWΦ219 high frequency longitudinally welded pipe production line is used to manufacture welded steel pipes of Φ76mm-Φ219.8mm with 2mm-6.5mm of wall thickness, which also can produce profiled pipes within the limit of processing round pipes. After absorbing advanced pipe making technology from both abroad and domestic, our innovative designed production lines are both economical and practical.
Technical Flow:
Uncoiling - Flattening-Shearing&butt welding-Strip Accumulating-Forming-High-frequency induction welding-Bead and burr removing-Zinc patching -Cooling-Sizing Inside Removing-UltrasonicTesting-Cutting-Checking &Collecting-Binding-Weighing-Marking-Accessing Warehouse
Specifications
1.Product Specifications
I. Round pipe diameter range: Φ76mm-219mm
wall thickness :2mm-6.5mm
II. Square and rectangle tube : 60*60mm-180*180mm
wall thickness range 2-5mm
III .Tube and pipe length: 6--12m
2. Material Specifications:
Low carbon steel and low alloy steel: δb≤500Mpa
δs≤235Mpa
3 Line specification
production speed:0-50m/min
Line Direction: right to left(from operator' s side)
