Specifications
1.Wind protection.2.Overload protection.
3.LED.
4.When confronted with the blackout.
5.Flexible start-stop function.
1
The material is refined using high-quality aluminum alloy . Thickness is 1 mm, height is 1.4—1.6m.
Flexible start-stop function: the newest microelectronic control technology and mechanical cushioning device used in conjunction , eliminate the impact of start and stop timing of the first moment , run more stable and smooth.
2
Overload protection and run-time protection: Unique user-friendly design, greatly extend the life of the motor.
3
Blackout door manual switch function: When confronted with the blackout. Just gently rotating with special keys can be clutch switch machine to run manually.
4
Magnetic induction stroke limit: running nose in place to ensure accurate.
5
Barriers to auto-back function: case of 30-50cm or obstacles can be automatically returned to protect the safety of pedestrians and vehicles
6
Built-in remote control function
7
LED display: According to the need for normal display (arrows show the direction of), a fixed display (Welcome and out of peace) and Rolling Display (according to everyone in the user asked to enter a maximum of 500 characters).
8
Interchangeable faceplates: Unique-style door panel can change the design, users can replace the door panel preferences at any time, often for fresh, absolutely excellent value for money.
9
Air rubber walking round: special surface stripe design, can effectively overcome the surface sediments of silt, cutting non-slip abrasion resistance, grip and strong, the internal mosaic bearing rotation, to ensure the smooth running telescopic doors.
10
Wind function: the form of whole body and Track hinge and door widening approach, greatly increased wind resistance.
11 Another strong wind design of a variety of ways, users can install the location of the wind under the door level matching.
Technical data
input voltage |
220VAC±10%50~60MHz |
transmission frequency |
433.92MHz |
Height |
1.4/1.5/1.6/1.7M |
Param encoding |
Rolling |
Operating temperature |
-20~50 centidegree |
Remote battery |
27A 12V |
Operating humidity |
≤90% |
spread length |
350-500MM |
|
|
Remote distance |
≤40M |
