Split Pressurized Solar Water Heater Made In China

Specifications

Split Pressurized Solar Water Heater Made In China
Popular market:USA, Europe, Canada, Russia, Australia, New Zealand and etc.

    Split Pressurized Solar Water Heater Made In China



Featrues:

1. It is not easy to be frozen and cracked down even in hash weather.
2. The shortcoming of bursting of tube or water leakage due to aged rubber ring is eradicated;
3. The water tank is welded scientifically under the high frequency weld and argon-arc weld. The integrated pressurized vacuum tube solar water heater can be directly connected with tap water system to operate automatically with pressure-bearing.
4. Water proof grade: IP *4
5. Hot water can be used directly, or can be used as a pre-heat.
6. Electric heater can be used 1500W or 3000W
7. The standards of vacuum tubes with heat pipe: 14, 16, 18, 20, 24, 30, or 36 units.
8. Water capacity: 100L, 150L, 200L, 240L, 300L and so on
9. Hail resistance: 25mm (diameter)

10. The time of heat insulation: 72h

11. High heat effectiveness: Higher than all glass evacuated solar collector tube by 15



Working principles:

The water tank is separated from collector. Split pressurized vacuum tube solar water heater is convenient to install and use. It works with pressure up to 0.6 MPa and can normally work in all climates. The absorptive coating of vacuum tube is ALN/ALN-SS/CU. This coating has high absorbing ratio (0.94) and low emission ratio (0.6). The heat efficiency is 0.64. The life span of vacuum tube is 15 years. The vacuum tube is made of borosilicate 3.3. No water in the vacuum tube. Even if some vacuum tubes are broken, the split pressurized vacuum tube solar water heater can normally work.



Specifications:
1. Vacuum tube:  58/1800mm heat pipe solar vacuum tube

2. Copper header inside:  0.8mm thick red copper header inside

3. Outer shell:  1.6 mm thick aluminum alloy outer shell

4. Insulation layer:  35mm thick polyurethane foam insulation

5. Bracket:  45 degree 1.5 mm thick galvanized sheet steel

6. Size: 120mm*115mm

7. Application: split solar water heating system



Advantages:

1. More high efficiency and less heat loss

2. Heat pipe solar vacuum tube

3. No water in heat pipe

4. Popular market: USA, Europe,Canada, Russia, Australia,New Zealand,and etc

5. Highly efficient insulation with polyurethane foam

6. Can be used all year round even in the cold weather

7. Automatically controlled
