Electricity Controller for soalr systems
Main technical data
1. Dimension: 210 mm x 145mm x 40mm
2. Self power consumption: 3W
3. Measuring accuracy of temperature:±2°C
4. Temperature range of measurement:0~99°C
5. Maximum power of controlled pump: 600W
6. Power of accompanied electrical heating wire: 800W
7. Power of auxiliary electrical booster: 2000W(standard collocation), 3000W
(not standard, selection available)
8. DC 12V, AC 220V, pressurized valve and un-pressurized valve are available for selection
Operation pressure of pressurized valve: 0.02Mpa~0.8Mpa, suitable for providing water directly
Operation pressure of un-pressurized valve: 0.0Mpa , connected with water tank or low
pressure water providing.
Main functions
- 1. Water temperature display
- 2. Water level display
- 3. Water level pre-setup
- 4. Manual water loading
- 5. Temperature controlled water loading
- 6. Timing water loading
- 7. Water loading when tank is lack of water
- 8. Compulsive water loading
- 9. Increasing Water pressure during water is loaded.
- 10. Water temperature pre-setup
- 11. Manual heating
- 12. Timing heating
- 13. Hot water circulation
- 14. Hot water pipe insulation
- 15. Low pressure protection
- 16. Collector tube protection
Our company is a manufacturer of solar collectors and solar water heaters in China .We have ISO certification and some other related certifications.We always give our customers best price and good quality! We sincerely hope you will be my next business friends.
