IR RGB led controler SMD5050 LED lamp wick LED Light base for LED furniture

FOB Price

USD $1 - $50 / Piece

50 Pieces(Min.Order)

Supply Ability 5000 Piece / Pieces per Month
Port Guangzhou shenzhen
Payment TermsT/T D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	KUDE
Model Number	KD-CU004

Product Description

IR RGB led controler SMD5050 LED lamp wick LED Light base for LED furniture

SMD5050 lamp:
1pcs RGB lamp wick=20mA
1pcs White lamp=36mA
85mm lamp base: 8pcsRGB lamp+4White lamp
102mm lamp base: 12pcs RGB lamp+6White lamp
117mm lamp base: 18pcs RGB lamp+6White lamp

Remote control:	1.turn on or turn off
	2.changing the color
	3.Adjust the brightness of the lights
	4.Adjust the flash of lights(4mode:Colorful gradient, colorful hopping, monochromatic flashing, colorful flicker
	5.Control distance 10-12M
Power supply:	Adaptor and battery
Power adaptor:	Adaptable voltage : AC110v-240v
Voltage and Power:	5V,10W
Battery:	1. Rechargeable Lithium battery
	2. Can be used for 10-12 hours continuously
	3. Battery charge time: 4-5 hours
	4. Battery included with safety strip
	5. Battery life span: 50000 hours
	6. Running time:10hours
battery capacity:	1000mA/H;1600mA/H;2200mA/H;3000mA/H;4400mA/H;6600mA/H(according to the LED bead lamp quantity)

Four keys Protection Function:

1.Battery protection: When battery charging to 28v, the batter will cut off power supply Automatically.

2.Short circuit Protection: It's Effective for metal. When the metal touch charging plug, it will cut off power automatically.

3.Voltage Protection: When the battery test 4.28v voltage, it will cut off power automatically.

4.Charger Protection: When Plus-n-Minus is short circuit, the voltage will be down 0V;

Charger is with voltage testing function:

when charging reach 4.1V, It will cut off automatically;

when charging reach 4.23V,charger willturn green light

when charging reach 4.28V, charger will cut off power supply.

Product Function:

1. Product control method are infrared, wireless, touch wireless, DMS, sound control, light control, mobile phone WIFI control (according to your requirement)

2.The product supply voltage: DC4.2v, DC12v, AC86-256v (according to your requirement)

3.The product can be controlled according to the above method to achieve monochrome conversion (according to the remote control at the color palette select the color you want)

4.Function mode key: Colorful gradient, colorful hopping, monochrome flashing, colorful flicker, adjustable flashing speed etc..(can be customized according to your requirement)
