4-Stroke 5hp Diesel Engine 170F
1. Silent Cart Type / Open Type is optional
2. Power output: 2-6KW 50/60 HZ
3. Copper/ Aluminium Alternator is optional
4. High quality Muffler/ Silencer with low noise
5. Alert if the power output exceeds the max power
6. Low Oil Pressure Alarm System
7. With/ Without ATS (Automatic Transfer Switch) system is optiona
8. With/ without Digital Voltmeter is optional
9. Single-phase or three-phase is optional
| NAME | ITEM | LFD170F | |
| Diesel Engine | EngineType | Single cylinda;4-stroke;air-cooled diesel engine | |
| Combustion system | Direct Injection | ||
| Bore x Stroke(mm) | 70x55 | ||
| Displacement(CC) | 211 | ||
| Engine Speed(rpm) | 3000 | 3600 | |
| Maximum Output(hp) | 3.8 | 4.2 | |
| Continuous Output(hp) | 3.4 | 3.8 | |
| Power take off | Crankshaft or camshaft(camshaft PTO rpm is1/2) | ||
| Start System | Recoil or electric(optional) | ||
| Fuel tank capacity(L) | 2.5 | ||
| Lube oil capacity(L) | 0.75 | ||
| Dimensions( Lx Wx H)(mm) | 420X360X460 | ||
| Net Weight (recoil)(kg) | 27 | ||
| Net Weight (electric)(kg) | 32 | ||
| Fuel type | 0#,-10#,-20# | ||
| Lube oil type | CD Grade or SAE 10W-30,SAE 15W-40 | ||
| Option | Oil bath air cleaner | ||
1.Q:Are you a factory or trading company?
A:We are a factory.
2.Q:Where is your factory located? How can I visit there?
A: Our factory is located in Taizhou City, Zhejiang Province, China, about 3 hours train from Shanghai . All our clients, from home or abroad, are warmly welcome to visit us!
3.Q:What is the material of your products?
A: Only New material can be used for our products.
Materials for Generator: 100% Pure Crankcase, 100% Pure Copper Wire
Materials for Water Pump: 100% Pure Auminium Pump body and Crankcase
4.Q:What is Minimum Order quantity?
A: MOQ 50/100 pieces for different products.
You are welcomed to consult for details.
5.Q:How does your factory do regarding quality control?
A: From the internal parts to the outside packing, we not only make standard quality test,but also think ahead for a better solution. Except company QC system, We have achieved CE & SONCAP certificate.
