Best Selling Heat Pipe Solar Collector

Name: Best Selling Heat Pipe Solar Collector
Brand: SUNLAND
SKU: 124270797
Availability: InStock

Negotiable MOQ: 5 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

SUNLAND

Model Number:

CDSC

Haining Chaoda Solar Collector Tubes Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name SUNLAND

Model Number CDSC

Type Other, Pressurized, Manifold Collector

Application Solar Thermal

Pipe Material Glass

Best Selling Heat Pipe Solar Collector

characteristic for solar thermal collector can widely using in big heating project.

The outlet pipe is now positioned at the back of the Collector to allow flush installation of 2 or more collectors and keeping pipework out of site

New slimline Manifold design and light, powdercoated aluminum frame, will look great on your roof.

New UV resistant clip-in-cups for effortless installation and protection of glass tubes

Technical Data of Heat pipe collector
Production Model		HCA-58/30	HCA-58/20
Numbers of tube(pcs)		30	20
Absorber area approx.(m2)		2.439	1.626
Aperture area(m2)		2.856m2	1.891m2
Gross size(m)		2.11.990.154	1.41.990.154
Fluid volume(L)		1.7	1.2
hot water(L/Day)(17MJ/m2.day,ΔT=35°C)		270	180
Weight Empty(kg)		93.5	63
Min. volume flow rate per collector(L/H)		108	72
Rated volume flow rate per coll.(L/H)		180	120
Max. volume flow rate per collector(L/H)		1200	1200
Maximum operation pressure(Bar)		6
Test pressure(Bar)		9
Heat transfer fluid		Anti-freeze Fluid (Water-Glycol)
Hydraulic Connections	On top	G3/4" male thread
	Both sides	Φ22 straight copper
Max. working temp.(°C)		250
