Electric cartridge heater with metal sheath provide superior heat transfer, uniform temperatures, resistance to oxidation and corrosion and long life even at high temperatures. Flexible lead wire extensions or other mounting options are available for specific applications.
Applications of the electric Heated Tube:
1. Caustic Cyanide used in gold processing
2.Hot water storage
3.Asphalt Wax
4.Caustic solutions Detergent
5.Sterilizing equipment
6.Heating oils
7.Plastic processing&packaging machinery
8.Ovens&dryers
9.Dies&Tools
10.Water& Oil heating appliances
11.Vending machines
12.Kitchen equipments
13.Medical equipments
Standard tube diameters are 6mm, 8mm, 10mm, 12mm and 16mm, but other special sizes are available for electric cartridge heater 12v. Depending on the diameter, lengths can be supplied up to 3000mm. Standard sheath materials are Stainless Steel 201, 304, 316 and 321, but special sheath materials may be available based on diameter and size of the element required.
Characteristics & Properties :
1.simple structure
2.long-time usage
3.high efficient heater exchange
4.it could easy to bent into many kinds of shape
5.good insulation could withstand high voltage
Main technical parameter:
Heat intensity |
Not exceeding 30Wcm2 (advisable) |
Power |
Depends on the dimension |
Escape of current (when cold) |
<=0.1mA a 242 v. |
Insulation (when cold) |
5 Min Ohmios 500 Watts minimum |
Dielectric strength |
1500v. 1/seg |
Working temperature |
750ºG max. |
Tolerance of length |
+/-1.5% |
Tolerance of diameter |
-0.01 a -0.06 m/m |
Tolerance of cut of connexion |
+/-15 mlm |
Power tolerance (w) |
5 % - 10 % |
Cold areas |
Depends on length and diameter 5-25mm |
Nomal Packaging: Use KINGSON brand wrapping plastic film or brand carton box in condition.
Delivery Detail: 5-15days after we receive all the payment.
