High Frequency Online 6 Kva Ups

High Frequency Online 6 Kva Ups thumbnail-1
High Frequency Online 6 Kva Ups photo-1
US$ 400 - 1,300 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Greentechy
Model Number:
HP-C6K
Contact Supplier Request Quote Chat Now
Foshan Greentechy Energy Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Foshan
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Greentechy
Model Number HP-C6K
Phase Single Phase
Protection Other, Short Circuit, Overload
Weight 35KG
Output Voltage 220/230VAC
Type Other, On-line, High frequency online indoor UPS
Application Other, All kinds office equipment,computer

Specifications

1. True online double conversion
2. Controlled by DSP+CPU
3. DC start & Auto restart function
4. Adaptable with generator



High frequency online 6 kva ups



I am Vivian cheng. Any information you need, please contact me directly.



              Your satisfaction is my biggest motivation.



Email: sales01 at



              Phone: 0086 15014635964



              Skype: greentechy-sales01







===============================================================



High frequency online 6 kva upsHigh frequency online 6 kva ups



Features:



1.True on-line double conversion technology
2.Highest reliability and maximum performance for power parallel and redundancy N+X
3.Super wide input voltage range and fully AVR
4.High input power factor
5.Zero transfer time
6.Controlled by fully digitized DSP+CPU
7.Self diagnosis and protection
8.Protection against all types of power problems
9.Miniaturization design,save on invaluable space
10. No add-on CNTL unit required for future  expansion
11.Advanced IGBT power components,which enhancing the overall reliability and conversion efficiency
12.Equipped with Maintenance Bypass Switch to achieve online maintenance
13.Smart local and distance  monitoring capability with RS232 port,and compatible with SNMP
14.LCD display with information available at a glance



Model: HP-

E6022M
  E6022L
E1032M
E1032L
E1034L
E1534L
E2034L
C6022M
C6022L
C1032M
C1032L
C1034L
C1534L
C2034L
Max.capacity(VA/W)
6KVA
6KVA
10KVA
10KVA
10KVA
15KVA
20KVA



Input

Input wiring

Single-phase line two+Ground line

Three-phase line four+Grround line

Voltage range
176--276VAC
304--478VAC

Frequency range
46--54 Hz

Power factor
≥0.95


Output
 Voltage
220VAC±2%
Frequency

Input synchronized the supply frequency(line mode), 50 Hz±0.1%(Battery mode)

Power factor
0.7
Current crest artio
3:1
Wavefrom
Sine wave

Overload capacity
 110%-150% load, change to bypass after 3 seconds, 150% load holds 300ms.

Standard backup time(full or halfoad)
>7′/20′

>5′/30′

Efficiency
>91%
>90%

Voltage of the battery
240VDC
Transfer time
Zero interruption
Automatic Bypass
Integrated
Indicator

Indicates load/battery capacity,UPS running states etc

Audible alarm
Battery discharge

Sounding every 4 seconds when mains fails
UPS Abnormal
Beeping continuously

Parellel Port (option)
Up to three units in parallel for power redundancy ang load sharing
Communication interface

RS232+SNMP(option)

Operating environment
Temperature
0--40
Humidity
20%-90%,No condensate
External/Shipping Size
(W×D×H)
260×570×720/450×705×1000
Net/Gross weight(kg)
84/94.5
35/52
84/94.5
35/44
35/48
55/72
55/72
Option
(SNMP Adapter),(Battery cubicle),(Parallel Port),(Maintenance Switch)





High frequency online 6 kva ups



High frequency online 6 kva upsHigh frequency online 6 kva ups
