LED Solar Street Light System 100W

Name: LED Solar Street Light System 100W
Brand: Greentechy
SKU: 124242719
Availability: InStock

US$ 800 - 1,600 MOQ: 1 Piece

Key Specifications

LED Light Source:

Highpower

Input Voltage(V):

24VDC

Lamp Power(W):

100

Foshan Greentechy Energy Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Foshan

Delivery Detail:

Delivery time depends on order quantity.

LED Light Source Highpower

Input Voltage(V) 24VDC

Lamp Power(W) 100

Lamp Luminous Flux(lm) 16800

Lamp Luminous Efficiency(lm/w) 110

Color Temperature(CCT) Pure White

Working Temperature(℃) -60, -20

Working Lifetime(Hour) 50000

Lamp Body Material Aluminum

IP Rating IP65

Warranty(Year) 1

Place of Origin Guangdong, China

Brand Name Greentechy

Model Number 100w LED solar street light system

Specifications

LED & PV street/ourdoor lighting
mono solar panel, VRLA battery
10-12 hours working model
complete system available

Items	Solar street light system
Solar panel	Mono crystalline silicon power: 100Wp*4pcs (100w mono panel efficiency: 18.4%)
Battery	High efficiency, SRS specially design for solar application GEL battery, 12V 200Ah*2
Controller	24V 20A, LED indicator, IP21, over charge , discharge protection, temperature compensation and so on
Solar panel bracket	4×1.2CM angle Iron, hot dip galvanized type, plastic-coating / painting.
Pole	10m, high carbon steel, hot dip galvanized type, plastic-coating / painting.
Lighting source	100W LED lamp, Super Bright LED,110Lm/W, can form 4:1 rectangular shape lighting distribution without Lens or with 120°Beam angle. The central brightness is up to 45LUX.
cable	2.5mm2×2, SRS specially design for solar application, silicon rubber with purple copper cable.
cabinet	Contain battery and controller, installed in the ground
packing	Cartons / MDF (Middle Density Fiberboard)
Working mode	about 10-12 hrs
Reliability	Guarantee 100% lighting throughout the year
Ambient temperature	-20°C to 60°C
