Jinan HEGNQI Engineering Machinery CO., Ltd is a professional construction machinery manufacturer which is established in 1987 with more than 100 workers, covering an area of square meters.
We have strong technical force, adopts advanced process equipment for CO2gas shielded arc welding, submerged arc welding, and complete testing methods and management systems. Our main products include QTZ series tower crane, SC series construction hoist, ZLP series suspended platform concrete machinery.
Product Introduction
Construction hoist is widely used in the vertical transportation of personnels and materials. It ‘s a good indispensable transportation equipment in the area of industrial and civil buildings, bridges, large shaft.aAs a permanent or semi permanent, it can also be used for different occasions such as warehouse, tower and so on. Compared with the other lifting mechanism the product is stable, safe and reliable, without additional room.It has the advantages of convenient assembly and disassembly, handling flexibility strong advantages, especially in reducing the construction personnel's labor intensity, speed up the project progress, improve the work efficiency.
Product Feature.
This kind machine has reasonable design, novel structure, stable operation, reliable safety device, convenient installation and maintenance, mainly has the following features:
1, the driving mechanism adopts three motor drive form, so that the gear rack is uniform, safe and stable.
2, to ensure the safe operation of the elevator, the circuit set the overload, speed limit and other safety switches, when the operation occurs in the above case, the elevator automatically to avoid accident. The door of the hanging cage is also limited to a switch, and when any door is opened, the suspension cage can not start or stop running immediately.
3, each cage is equipped with anti falling safety device, can effectively prevent cage falling, to ensure safe and reliable operation of the elevator.
4, elevator control system circuit is simple, easy to operate and maintenance, and reliable. During normal operation of the elevator, the hanging cage with a handle or a button control elevator operation, in any parking position can be stopped at any time, in the upper and lower terminal station, the upper and lower terminal limit switch control automatic parking, if the terminal limit switch for fault does not play a role, the lifter is provided the limit switches can be promptly cut off the power supply of the brake.
5, the steel structure design through scientific and rigorous calculation, achieve reasonable structure, reliable strength, light weight requirement.
6, the elevator can use the cage on the hanger to install or remove the guide frame. Convenient installation and disassembly of each part can be the rest of the parts can be easily replaced.
Product Parameters
Product Picture
Spare Parts.
1- cage 2-rope pulley 3-lamp 4-roller 5-roller spanner 6-cable joint 7-cable joint 8-gate roller lower 9-gaterroller upper 10-screw 11-nylon wheel 12-protect hook 13-mast section 14-rack 15-“J”screw
Spare Parts.
16-safety device 17-out operate box 18-safety device spanner 19-drop test operate box 20-3 phase switch 21-limint switch 22-motor 23-coupling 24-pinion 25-spring 26-adjustment unit 27-brake pad 28-jacket 29-rubber 30-brake disc 31-brake piece 32-electromagnet 33-rubber pad 34-reducing device 35-worm wheel 36-worm 37-oil seal 38-bearing 39-counter roller 40-worm gear fan
Spare parts.
41-creepage switch 42-overload 43-brake unit 44-drop test plug 45-transformer 46-contactor 47-PLC module 48-fan 49-thermal relay 50-belling 51-calling system
Spare Parts.
52-master controller 53-emergency stop button 54-hander switch 55-bell switch 56-lamp switch 57-EL.lock 58-Hydraulic spring 59-water proof plug 60-annunciator 61-resistance 62-pipe joint
Delivery:within 7-15 days after receiving advance payme.
Package:Standard export package.
Before sale
Pls tell me your requirments such as the building heught,max load,lift height,span,other specials you want.We will provide you with suitable model according to your request.If have any questions,our technician will help you solve.
On sale
Free of charge to accompany clients to inspect machines,to assist in the development of construction plan,to pack machine and delivery as well as assist customers to formulate the installation schedule.
After sale
1）- One year warranty for the machines.
2）- Offer free quick-wear accessories.3） Low charge for continue maintenance when warranty is expired.
4）- Exclusive engineer support at any time.
5）Provide free training to end-users.
