Help CenterNylon Expandable Sleeving
US$ 0.01 - 1.99
MOQ: 1000 Meters
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
JDD
Model Number:
PA-025
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Expandable Braided SleevingUS$ 0.1 - 1MOQ: 1000 Meters -
Flexo- JDD Expandable Sleeving for Baby Playing SleeveUS$ 0.1 - 1.5MOQ: 3000 Meters
-
Polyester Braided Expandable SleevingUS$ 0.1 - 3MOQ: 2000 Meters
-
Wire MeshUS$ 0.1 - 3MOQ: 4000 Meters
-
PET Braided Expandable SleevingUS$ 0.09 - 2MOQ: 3000 Meters
Place of Origin
China
Brand Name
JDD
Model Number
PA-025
Type
Other, expandable
Material
Other, PA(polyamide)
| Nylon expandable sleeving |
| JDD- PA braided sleeving is made of nylon 6.6 and offers excellent performance of abrasion resistance. It maintains a high degree of flexibility and it can resists to many chemicals agents. Uniquely shaped monofilament provides smooth, soft, slick surface resisting snags when dragged over rough surface. |
The product is most commonly used to protect wire harnesses, cable assemblies, air conditined pipes, fluid pipes in automotive, aerospace and military applications.
| Technical data | |
| Material | Polyamide 6.6 |
| Operating range | -60℃-+160℃ |
| Melt point | 256±5℃ |
| Flnmmability | VW-1 |
| Standard color | Black and grey |
| Certificate | ROHS |
| Cutting tool | Hot knife |
| Datasheet | |||||
| Nominal sizeW | Part No. | Expanded range mm | PackingL | ||
| Inch | mm | Min.I | Max.O | Standard spool | |
| 1/8" | 3 | PA-003 | 1 | 6 | 1000 m |
| 1/4" | 6 | PA-006 | 3 | 9 | 500 m |
| 5/16" | 8 | PA-008 | 5 | 16 | 350 m |
| 3/8" | 10 | PA-010 | 7 | 19 | 350 m |
| 1/2" | 12 | PA-012 | 8 | 24 | 300 m |
| 5/8" | 16 | PA-016 | 10 | 27 | 250 m |
| 3/4" | 19 | PA-019 | 14 | 30 | 200 m |
| 1" | 25 | PA-025 | 18 | 35 | 200 m |
| 1 1/4" | 30 | PA-032 | 20 | 50 | 150 m |
| 1 1/2" | 40 | PA-038 | 30 | 60 | 100 m |
| 1 3/4" | 45 | PA-045 | 35 | 75 | 100 m |
| 2" | 50 | PA-050 | 40 | 80 | 100 m |
| 2 1/2" | 64 | PA-064 | 45 | 105 | 100 m |
| 3" | 76 | PA-076 | 64 | 120 | 100 m |
| Unit:mm | |||||
Notes:
1. Nominal size indicates the flat width.
2. Special packages, sizes, and colors can be supplied upon request.
3. All numerical data are average or typical value, not including customized sizes.
