pet braided expandable hose

Specifications

pet braided expandable hose
Low price
high quality
short lead time

pet braided expandable hose consists of flexible, flame-retardant woven polyester that met
RoHS stantard. The braid is able to expand up to 3 times its normal size and isused for bunding and protectiong of electrical cables in power-supply machineand automobile sectors. Material: polyester (PET) monofil free of hologen

Technical data Material Polyester Operating Temperature -50℃-+150℃ Melt point 240±10℃ Flammability VW-1 Standard color  Black and grey Approval UL,ROHS,PFOS,REACH,Halogen Free Cutting tool Hot knife



Datasheet Nominal sizeW Part No. Expanded range PackingL Inch mm Min.I Max.O standard spool 1/8" 3 FR-003 1 6 1000 m 1/4" 6 FR-006 3 9 500 m 5/16" 8 FR-008 5 16 350 m 3/8" 10 FR-010 7 19 350 m 1/2" 12 FR-012 8 24 300 m 5/8" 15 FR-016 10 27 250 m 3/4" 20 FR-019 14 30 200 m 1" 25 FR-025 18 35 200 m 1 1/4" 30 FR-032 20 50 150 m 1 1/2" 40 FR-038 30 60 100 m 1 3/4" 45 FR-045 35 75 100 m 2" 50 FR-050 40 80 100 m 2 1/2" 64 FR-064 45 105 100 m 3" 76 FR-076 64 120 100 m           Unit:mm
