Mesh Tube

Mesh Tube photo-1
Mesh Tube photo-2
Mesh Tube photo-3
Mesh Tube photo-4
Mesh Tube photo-5
Mesh Tube photo-6
US$ 0.045 - 6.523 MOQ: 3000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
JDDTECH
Model Number:
JDD-FR
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name JDDTECH
Model Number JDD-FR
Type Other, PET cable sleeving
Material Other, Polyester

PET braided expandable sleeving/flexible net/PET hose is flame-retardant and halogen-free. It offers durable abrasion resistance in a wide range of industrial applications. The open weave construction allows an easy installation on a bundle of hoses and cables, even if some with bulky or large connectors.

Totally expanded the sleeving can reach at least 1.5 times than the initial dimension.





Technical data
Material Polyester
Operating Temperature -50℃-+150℃
Melt point 240±10℃
Flammability VW-1
Standard color  Black and grey
Approval UL,ROHS,PFOS,REACH,Halogen Free
Cutting tool Hot knife







Datasheet
Nominal sizeW Part No. Expanded range PackingL
Inch mm Min.I Max.O standard spool
1/8" 3 FR-003 1 6 1000 m
1/4" 6 FR-006 3 9 500 m
5/16" 8 FR-008 5 16 350 m
3/8" 10 FR-010 7 19 350 m
1/2" 12 FR-012 8 24 300 m
5/8" 15 FR-016 10 27 250 m
3/4" 20 FR-019 14 30 200 m
1" 25 FR-025 18 35 200 m
1 1/4" 30 FR-032 20 50 150 m
1 1/2" 40 FR-038 30 60 100 m
1 3/4" 45 FR-045 35 75 100 m
2" 50 FR-050 40 80 100 m
2 1/2" 64 FR-064 45 105 100 m
3" 76 FR-076 64 120 100 m
          Unit:mm
