Description:
JDD high abrasion resistant expandable sleeving can improve about 300% the abrasion resistance of standard polyester expandable sleeving. It is a good solution where exists a big friction between different parts, and is required a critical surface protection.
Application:
The PET high anti-abrasion braided sleeving is not only commonly used in rubber hose, railway, underground, wire bundles, but also be used to protect lines on foklifts, welding machines, and hydraulic lines on heavy equipments.
Technical data:
Material: Polyester
Operating range: -50 °C ÷ +150°C
Melt point: 250±5°C
Flammability: VW-1
Standard colours: black, grey
Certified: UL, CSA, RoHS, PFOS, REACH, Halogen Free
Cutting tool: hot knife
Dimensions:
| Datasheet | |||||
| Nominal sizeW | Part No. | Expanded range mm | PackingL | ||
| Inch | mm | Min.I | Max.O | Standard spool | |
| 1/8" | 3 | FRL-003 | 1 | 6 | 1000 m |
| 1/4" | 6 | FRL-006 | 3 | 9 | 500 m |
| 5/16" | 8 | FRL-008 | 5 | 16 | 350 m |
| 3/8" | 10 | FRL-010 | 7 | 19 | 350 m |
| 1/2" | 12 | FRL-012 | 8 | 24 | 300 m |
| 5/8" | 16 | FRL-016 | 10 | 27 | 250 m |
| 3/4" | 19 | FRL-019 | 14 | 30 | 200 m |
| 1" | 25 | FRL-025 | 18 | 35 | 200 m |
| 1 1/4" | 30 | FRL-032 | 20 | 50 | 150 m |
| 1 1/2" | 40 | FRL-038 | 30 | 60 | 100 m |
| 1 3/4" | 45 | FRL-045 | 35 | 75 | 100 m |
| 2" | 50 | FRL-050 | 40 | 80 | 100 m |
| 2 1/2" | 64 | FRL-064 | 45 | 105 | 100 m |
| 3" | 76 | FRL-076 | 64 | 120 | 100 m |
| Unit:mm | |||||
Notes:
1. Nominal size indicates the flat width.
2. The part No. will be followed with BK, GR and so on to indicate the colour of sleeving.
3. This sleeving has expandable character, the following sizes are covered by the nearest:
16mm= 15mm, 19mm =20mm, 32mm =30mm, 38mm =40mm, 51mm =50mm.
4. Special packing, sizes and colours can be supplied upon request.
