JDD-MCBG Thin wall heat shrinkable tube is made of modified polymers and cross-linked by electronic accelerator. It is ideal solution for insulation, flame retardant, high flexibility and quick shrinking for some precision components.
Application: It is widely used in the fields of electrics, communication, automobile for connection insulation and rust-proof of metal products where the ultra thin wall thickness is required.
Technical data:
Material: Polyethylene
Working temperature: -55℃~+125℃
Shrink temperature: Start at 70℃, complete shrink at 110℃
Longitudinal shrinkage: ≤5%
Flammability: VW-1
Shrinkage ratio: 2:1
Color: Black
Tool: Heat gun
Approval: UL, CSA, RoHS, Halogen free
Remark: The clear color tube operating temperature is 105℃
Dimensions:
Part No. |
As supplied |
After recovery |
Packing (m) |
|||
I.D. mm |
Wall thickness mm |
Max. I.D. mm |
Wall thickness mm |
|||
MCBG-1.0 |
1.5±0.3 |
0.12±0.05 |
≤0.65 |
0.20±0.10 |
200 |
|
MCBG-1.5 |
1.9±0.3 |
0.13±0.05 |
≤0.85 |
0.20±0.10 |
200 |
|
MCBG-2.0 |
2.4±0.3 |
0.15±0.05 |
≤1.00 |
0.22±0.10 |
200 |
|
MCBG-2.5 |
2.9±0.4 |
0.15±0.05 |
≤1.30 |
0.25±0.10 |
200 |
|
MCBG-3.0 |
3.4±0.4 |
0.15±0.05 |
≤1.50 |
0.28±0.10 |
200 |
|
MCBG-3.5 |
3.9±0.4 |
0.15±0.05 |
≤1.80 |
0.28±0.10 |
200 |
|
MCBG-4.0 |
4.4±0.4 |
0.18±0.05 |
≤2.00 |
0.30±0.10 |
200 |
|
MCBG-4.5 |
4.9±0.4 |
0.18±0.05 |
≤2.30 |
0.30±0.10 |
200 |
|
MCBG-5.0 |
5.5±0.4 |
0.18±0.05 |
≤2.50 |
0.32±0.10 |
100 |
|
MCBG-6.0 |
6.5±0.4 |
0.20±0.05 |
≤3.00 |
0.32±0.10 |
100 |
|
MCBG-7.0 |
7.5±0.4 |
0.18±0.05 |
≤3.50 |
0.32±0.10 |
100 |
|
MCBG-8.0 |
8.5±0.5 |
0.18±0.05 |
≤4.00 |
0.32±0.10 |
100 |
|
MCBG-9.0 |
9.5±0.5 |
0.18±0.05 |
≤4.50 |
0.35±0.10 |
100 |
|
MCBG-10 |
10.5±0.5 |
0.18±0.05 |
≤5.00 |
0.35±0.10 |
100 |
|
MCBG-11 |
11.5±0.5 |
0.18±0.05 |
≤5.50 |
0.40±0.10 |
100 |
|
MCBG-12 |
12.5±0.5 |
0.20±0.05 |
≤6.00 |
0.40±0.10 |
100 |
|
MCBG-13 |
13.5±0.5 |
0.20±0.05 |
≤6.50 |
0.40±0.10 |
100 |
|
MCBG-14 |
14.5±0.5 |
0.20±0.05 |
≤7.00 |
0.40±0.10 |
100 |
|
MCBG-15 |
15.5±0.5 |
0.20±0.05 |
≤7.50 |
0.40±0.10 |
100 |
|
MCBG-16 |
16.5±0.5 |
0.22±0.05 |
≤8.00 |
0.40±0.10 |
100 |
|
MCBG-18 |
18.0±0.5 |
0.22±0.05 |
≤9.00 |
0.45±0.10 |
100 |
|
MCBG-20 |
20.0±0.5 |
0.22±0.05 |
≤10.0 |
0.45±0.10 |
100 |
|
MCBG-22 |
22.5±0.5 |
0.22±0.05 |
≤11.0 |
0.45±0.10 |
100 |
|
MCBG-25 |
25.5±0.5 |
0.22±0.05 |
≤12.5 |
0.45±0.10 |
50 |
|
