Specifications
Shrinkabel rate: 2:1Thin wall thickness
Thin Wall Heat Shrinkable Tube is newly developed environment-friendly flame retardant heat shrinkable tube,using specially designed formulation of high polymers,through cross-link by electronic accelerator and continuous expansion.
The properties of environment-friendly,flexibility flame retardant,quick shrink and stable performance mark them widely used in the field electronics,communication,automobile,and wirely appied for conncting or end-harding,electric wire,insulatng and harness of electric wire
Halogen Free Flame-retardant Thin wall Heat Shrinkable Tube(metric) | ||||||||
Size |
As Supplied(mm) |
After Recovery(mm) |
Standard Package |
Aplication |
||||
I.D. |
Average W.T. |
Max.I.D. |
Average W.T. |
M/spool |
Spools/ |
Carton size(cm) |
||
Φ1.0CB |
1.50±0.3 | 0.12±0.05 | ≤0.65 | 0.20±0.10 | 200 | 19 | 31×31×44.5 | 0.7∼1.0 |
Φ1.5CB |
1.90±0.3 | 0.13±0.05 | ≤0.85 | 0.20±0.10 | 200 | 13 | 31×31×44.5 | 0.9∼1.4 |
Φ2.0CB |
2.35±0.3 | 0.15±0.05 | ≤1.00 | 0.22±0.10 | 200 | 18 | 46×46×44.5 | 1.1∼1.8 |
Φ2.5CB |
2.80±0.4 | 0.15±0.05 | ≤1.30 | 0.25±0.10 | 200 | 15 | 46×46×44.5 | 1.4∼2.3 |
Φ3.0CB |
3.40±0.4 | 0.15±0.05 | ≤1.50 | 0.28±0.10 | 200 | 13 | 46×46×44.5 | 1.6∼2.7 |
Φ3.5CB |
3.80±0.4 | 0.15±0.05 | ≤1.80 | 0.28±0.10 | 200 | 10 | 46×46×44.5 | 1.9∼3.2 |
Φ4.0CB |
4.40±0.4 | 0.18±0.05 | ≤2.00 | 0.35±0.10 | 200 | 8 | 46×46×44.5 | 2.1∼3.6 |
Φ4.5CB |
4.70±0.4 | 0.18±0.05 | ≤2.30 | 0.35±0.10 | 200 | 10 | 46×46×44.5 | 2.4∼4.0 |
Φ5.0CB |
5.50±0.4 | 0.18±0.05 | ≤2.5 | 0.37±0.10 | 100 | 10 | 46×46×44.5 | 2.6∼4.5 |
Φ6.0CB |
6.50±0.4 | 0.20±0.05 | ≤3.0 | 0.39±0.10 | 100 | 8 | 46×46×44.5 | 3.1∼5.4 |
Φ7.0CB |
7.5±0.4 | 0.18±0.05 | ≤3.5 | 0.32±0.10 | 100 | 20 | 31×31×44.5 | 3.7∼6.3 |
Φ8.0CB |
8.5±0.5 | 0.18±0.05 | ≤4.0 | 0.32±0.10 | 100 | 18 | 31×31×44.5 | 4.2∼7.2 |
Φ9.0CB |
9.5±0.5 | 0.18±0.05 | ≤4.5 | 0.35±0.10 | 100 | 18 | 31×31×44.5 | 4.7∼8.0 |
Φ10CB |
10.5±0.5 | 0.18±0.05 | ≤5.0 | 0.35±0.10 | 100 | 16 | 31×31×44.5 | 5.2∼9.0 |
Φ11CB |
11.5±0.5 | 0.18±0.05 | ≤5.5 | 0.40±0.10 | 100 | 15 | 31×31×44.5 | 5.7∼10.0 |
Φ12CB |
12.5±0.5 | 0.20±0.05 | ≤6.0 | 0.40±0.10 | 100 | 10 | 46×46×31 | 6.2∼11.0 |
Φ13CB |
13.5±0.5 | 0.20±0.05 | ≤6.5 | 0.40±0.10 | 100 | 9 | 46×46×29.5 | 6.7∼12.0 |
Φ14CB |
14.5±0.5 | 0.20±0.05 | ≤7.0 | 0.40±0.10 | 100 | 9 | 46×46×29.5 | 7.3∼13.0 |
Φ15CB |
15.5±0.5 | 0.20±0.05 | ≤7.5 | 0.40±0.10 | 100 | 8 | 46×46×29.5 | 7.8∼14.8 |
Φ16CB |
16.5±0.5 | 0.22±0.05 | ≤8.0 | 0.40±0.10 | 100 | 8 | 46×46×31 | 8.3∼15.8 |
Φ18CB |
18.5±0.5 | 0.22±0.05 | ≤9.0 | 0.45±0.10 | 100 | 7 | 46×46×29.5 | 9.3∼17.0 |
Φ20CB |
20.5±0.5 | 0.22±0.05 | ≤10.0 | 0.45±0.10 | 100 | 6 | 46×46×29.5 | 10.5∼19.0 |
Φ22CB |
22.8±0.5 | 0.22±0.05 | ≤11.0 | 0.45±0.10 | 100 | 6 | 46×46×29.5 | 11.5∼20.5 |
Φ25CB |
25.5±0.5 | 0.22±0.05 | ≤12.5 | 0.45±0.10 | 50 | 6 | 46×46×31 | 12.5∼25.5 |
