Copper foil shielding sleeving

Specifications

It is widely used for communication system, electronic medical
equipments, military equipments as well.
Shielding function!

JDD-SES copper foil shielding sleeving is woven with copper foil filament, it is used for various electrical and industrial fields where EMI shielding, excellent protection and lightweight are required. It is lighter and more flexible than tinned copper braided sleeving, it is a perfect combination of economy and durability, it can be used as connectors with highly flexible and easily to install.

Application: It is widely used for communication system, electronic medical equipments, military equipments as well.



Technicai data
Material	Copper filament
Operating range	-40°C-+150°C
Standard color	Tinned color
Certificate	ROHS
Cutting tool	Scissors
Other features	Resists gasoline and engine chemicals





Datasheet
Part No.	Nominal sizeW	Expanded rangel to O		PackingL
SES-004	4.0	3.0---7.0		300m/spool
SES-006	6.0	4.0---9.0		200m/spool
SES-008	8.0	6.0---12.0		200m/spool
SES-010	10.0	7.0---16.0		150m/spool
SES-012	12.0	8.0---20.0		100m/spool
SES-015	15.0	10.0---23.0		100m/spool
SES-020	20.0	13.0---28.0		100m/spool
SES-025	25.0	18.0---32.0		100m/spool
SES-030	30.0	20.0---40.0		100m/spool
SES-040	40.0	30.0---50.0		50m/spool
SES-050	50.0	40.0---60.0		50m/spool
				Unit:mm
