Help Center230v,50hz,2500rpm Shaded Pole MotorYJ62-30: ac Motor Electric for Nebulizer,air Pump,oxygen Machine,fan Motor
Related Products
-
Motor Electric Fan Motor Oven Motor YJ62-20:120/220V, 50/60hz, 2500-3000rpm Electric Motor SpecificationsUS$ 3 - 6MOQ: 1000 Units -
Fan Motor Shaded Pole Motor YJ62-20: Oven Motor Raditor Fan,120/220v,50/60hz,2500-3000rpm,VDE,UL,CE,CUL,CCCUS$ 3 - 6MOQ: 1000 Units
-
Piston Compressor Nebulizer Motor: Shaded Pole Motor, 230V 50/60 Hz, High Pressure, CE/UL/VDE CertifiedUS$ 5.42 - 5.73MOQ: 1000 Pieces
-
Nebulizer Motor: High Speed Low Noise Electric Single-phase Shaded Pole Motor CE/VDE/UL CertifiedUS$ 5.4 - 5.8MOQ: 1000 Pieces
-
Nebulizer Motor Single-phase SP Motor YJ62-45 Type for Home Appliance Fan Air Blower Air PurifierUS$ 4.65 - 7MOQ: 1000 Pieces
Specifications
Rated Voltage:100-240VACLaminations: 8--25mm
Size: 48*48mm
Life: 3000 Hours Min
Single Phase Shaded Pole motor is mainly composed of core, primary and secondary windings, rotor, stator and bobbin. Secondary winding is the short-circuiting ring, producing magnetic potential and forming a rotating magnetic field in the air gap. Rotor is made up of core and squirrel cage conductor. The function of squirrel cage conductor is to induce current and electromagnetic torque, realizing the conversion of electricity and motion energy.
Product General Performance Parameters:
Voltage----------------------100-240VAC
Frequency-------------------50/60HZ
Power------------------------5-100W
Insulation Class----------- -A/E/B/F/H
Noise--------------------------less than 43Db(A)
Life----------------------------5000-10000Hours
Core Thickness---------------8-40mm
Shaft Diameter(mm)---------Φ2.5,Φ3.17,Φ4.0,Φ4.6,Φ5.0,Φ5.5,Φ6.0,Φ6.35
Series: YJ62-30
Motor with pump assembly:
Motor with cross-flow fan assembly:
Characteristics:
Low noise, Stable operation, Long life, No electromagnetic interference, Less maintenance.
Application:
Ventilator, Nebulizer, Vacuum pump, Air pump, Oven, Oxygen concentrator
