Ductile Iron Pipe Rubber Gasket

FOB Price

US$ 0.1 - 10 / Piece

2000 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	China	Brand Name	KM
Model Number	KM-150116	Material	Other, Rubber: EPDM, NITRILE, SILICON
Shape	Ring Gasket	Standard or Nonstandard	Standard

Ductile Iron Pipe Rubber Gasket

Material: Nitrile, NR, EPDM, SILICONE, Viton, Neoprene, SBR, HNBR, ACM,etc.

Working Temperature: -40°C~+250°C

Color: Black, white, according to customers’ requirements

Hardness: 45 to 75 shore A or as your request.

Sizes for your reference, or as request.

External diameter of the pipe (mm)	Ring inside(mm)	Sealing ring diameter of section (mm)
600	575	19
700	665	19
800	778	19
900	845	19
1000	940	20
1200	1130	20
1400	1215	20
1600	1400	20
1800	1560	20
2000	1750	20
2200	1920	20
2400	2055	20
2600	2280	20
2800	2440	20
3000	2460	20

Feature of water supply project ductile iron pipes rubber square gasket

1. Low and high temperature resistance

2. Good sealing performance

3. Excellent oil resistance

4. Anti-aging, good flexibility, good elasticity

5. Excellent chemical corrosion resistance

Application of water supply project ductile iron pipes rubber square gasket

Pipeline interface, sealing for pipes, such as prestressed concrete cylinder pipe

Please feel free to send us inquiries and we are looking forward to

cooperating with you !
