Electric Furnace Used Spiral SiC Heating Element

Electric Furnace Used Spiral SiC Heating Element thumbnail-1
Electric Furnace Used Spiral SiC Heating Element photo-1
US$ 1 - 100 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, electric heater
Power Source:
Electric
Contact Supplier Request Quote Chat Now
Zhengzhou Lepe Refractory Materials Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Tianjin/Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, electric heater
Power Source Electric
Place of Origin Henan, China
Brand Name LEPE
Model Number LPSH-71
Dimension(L*W*H) customizable
Weight all depends
Voltage all depends
Power(W) all depends
Certification ISO9001

Specifications

Spiral SiC heating element
1.U, W, ED, DB, SCR, SC, UX type
2.Diameter:8-50mm
3.Customizable
4.ISO 9001

Electric furnace used spiral SiC heating element


1.Description

1) Non-metallic heating element, based on material of high quality green silicon carbide


2) Compared with metal, it is characterized by anti-oxidation, corrosion resistance, long service life, deformation, easy installation and maintenance.


3) Widely used in multiple high temperature furnace(magnetic material, powder metallurgy, ceramic, glass, metallurgy and mechanical used) and other electric heating devices


4) It can be used in air atmosphere without any protect atmosphere.


We make U, W, ED, DB, SCR, SC, UX type , also can be customizable



The diameter of heating element are 8mm, 10mm,12mm, 14mm, 16mm, 18mm, 20mm, 25mm,30mm,35mm, 40mm, 45mm, 50mm and so on.

spiral SiC heating element

2. Physical properties

Specific gravity

2.6~2.8g/cm3

Bend strength

>300kg

Hardness

>9MOH’S

Tensile strength

>150kg/cm3

Porosity rate

<30%

Radiancy

0.85

3.Electric properties
Electric furnace used spiral SiC heating element
                                                                                                                            Surface temperature of elements
  spiral SiC heating element
4. Chemical properties
1) Antioxidant property of elements

2)The effect of alkali and alkaline metal oxide to elements

The alkali and alkaline metal oxide will react with SiC at about 1300 °C and generate silicate, which calls alkali-chemical corrosion, and can influence the glowing of element evidentaly.

3)The effects to elements from melting metal

Some metals, such as cobalt, nickel, chrome and so on, can corrade the element in high temperature melting state and affect the service life of element.

5.Packing details
Electric furnace used spiral SiC heating element


Electric furnace used spiral SiC heating element


6.Why do you choose our spiral SiC heating element?

1) Accept customized

2) Installation technical guidance

3) Inquiries answered within 24 hours

4) Pay for it damaged in the transit
