Fully Automatic Nylon Pyramide Tea Bag Packing Machine
- 30 Set / Sets per Month
- shanghai
- T/T
- courrier poly mailer bags cutting and packing Machine
- automatic drink bag juice Bag Sachets Packing Machine
- automatic drink bag juice Bag Sachets Packing Machine
- Plastic Package Stick Packet Three sides Packaging Sealing Machine
- ziplock premade bag filling machine
- Friench Fries Popcorn Packaging peanuts packing machine
Product Details
Condition: | New | Application: | Other, Tea | Packaging Type: | Other, Bag |
Packaging Material: | Plastic | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | 220V | Place of Origin: | Shanghai, China | Brand Name: | Huihe |
Model Number: | Fully Automatic Nylon Pyramide Tea Bag Packing Machine DXPC-15 | Dimension(L*W*H): | 800*700*2000mm | Weight: | 800KG, 800KG |
Certification: | CE;ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
DXDPC-50 Fully Automatic Nylon Pyramide Tea Bag Packing Machine
Features
Nylon triangle tea bag adopt japan Environmental protection nylon and non-woven fabrics, non-toxic, non bacteria and thermotolerant high quality filter material, even the printing on the tag also made of japan non-toxic ink, which can be 100% degradable, reduce the the pollution problem. The sealing adopt the particular method, ultrasonic non-trace sealing, tightness,hygienism, safe, so as to reduce the redundant sealing width, will not waste any filter material, comparing with the common tea bag, after hot water entered, it can stretch at the highest speed and maintain original taste without damage to the tea bag. can mix with water for several times and long time, highlight the tenacity and durability of the packaging material , transparent mesh design make the aroma of the tea plays out vividly and incisively
Specification
Model No. | DXDPC-50 |
Method of measurement | Volume method or mulithead weigher(customizing) |
Range of measurement | ≤3±0.5 g / bag |
Requirement for tea | Length of tea≤15mm, with flatspot shape,otherwise measure precision will go down. |
Bag paper requirements
| Buyer buy the japan import tag, thread, nylon and non-woven fabrics byself (see the sample picture) |
Roll quantity
|
1piece |
Roll inner diameter
|
Φ76mm
|
Roll outer diameter
| ≤Φ400mm |
Sealing and cutting form | With the latest electric pulse sealing and cutting method |
Electrical configuration standard
|
Pneumatic element, button,
A.C contactor all from the overseas-funded enterprise or Sino-foreign joint venture enterprise products.
|
Air pressure
|
≥0.6Mpa
|
Inside motor power
|
about 1.1 Kw(380V)
|
Number of worker
| 1 |
Weight | 800KG |
After Sales Service
1.Guaranty: One Year.
2.One set of consumable accessories will be provided with the machine.
3.Any question, you can mail/call us at any time. And our most experienced engineers are assigned to give consulting service, and always available for dispatching abroad.
4.All spare parts are always available for delivery.
5.Manual is in English.
Installation/ Training
If really dont know how to install and operate after showing the video and telephone instruction, you can ask for installation from us. It must be after shipment till the machine has arrived and factory must be ready equipped with all necessary requirements before booking installation. Our engineers will come to the site for the complete and final installation. During the installation session, a one-day training course will be provided to our customers about operation and maintenance procedure. The following costs should be paid by the buyer, including engineer's all local transportation, accommodation, and air tickets (round trip).
Our packing samples
Green tea,red tea,flower tea,chinese tea,health tea,herb tea etc.
Payment terms
Choose the machine type → Goods delivery :(FOB,CIF,CFR,EXW) → Payment term :30% down payment as for ordering the machine (or 100 % payment that can save time ) → Confirmed the machine requirement → Based on your requested to producing machine→ Though video chat or send machine picture or directly come to inspection in our factory → Pay the rest of balance 70% → Arrange the shipment .(If need more technical support ,please contact our services )
