Home > Consumer Electronics > Warmer Appliance > Heater Fan > High Quality Furnace Used Silicon Carbide Rod Heater

High Quality Furnace Used Silicon Carbide Rod Heater

High Quality Furnace Used Silicon Carbide Rod Heater thumbnail-1
High Quality Furnace Used Silicon Carbide Rod Heater photo-1
US$ 1 - 100 MOQ: 5 Pieces
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, electric heater
Power Source:
Electric
Contact Supplier Request Quote Chat Now
Zhengzhou Lepe Refractory Materials Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Tianjin/Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, electric heater
Power Source Electric
Place of Origin Henan, China
Brand Name LEPE
Model Number LPSH-64
Dimension(L*W*H) customizable
Weight all depends
Voltage all depends
Power(W) all depends
Certification ISO9001

Specifications

Silicon carbide rod heater
1.U, W, ED, DB, SCR, SC, UX type
2.Diameter:8-50mm
3.Customizable
4.ISO 9001

High quality furnace used silicon carbide rod heater



1.Description of silicon carbide rod heater

1) Non-metallic heating element, based on material of high quality green silicon carbide

2) Compared with metal, silicon carbide rod heater is characterized by anti-oxidation, corrosion resistance, long service life, deformation, easy installation and maintenance.

3) Widely used in multiple high temperature furnace(magnetic material, powder metallurgy, ceramic, glass, metallurgy and mechanical used) and other electric heating devices

4) silicon carbide rod heater can be used in air atmosphere without any protect atmosphere.

We make U, W, ED, DB, SCR, SC, UX type , also can be customizable

The diameter of heating element are 8mm, 10mm,12mm, 14mm, 16mm, 18mm, 20mm, 25mm,30mm,35mm, 40mm, 45mm, 50mm and so on.

2. Physical properties of silicon carbide rod heater

Specific gravity

2.6~2.8g/cm3

Bend strength

>300kg

Hardness

>9MOH’S

Tensile strength

>150kg/cm3

Porosity rate

<30%

Radiancy

0.85
3.Electric properties of silicon carbide rod heater
High quality furnace used silicon carbide rod heater
                                                                                                                            Surface temperature of elements
 4. Chemical properties of silicon carbide rod heater
1) Antioxidant property of elements
2)The effect of alkali and alkaline metal oxide to elements
The alkali and alkaline metal oxide will react with SiC at about 1300 °C and generate silicate, which calls alkali-chemical corrosion, and can influence the glowing of element evidentaly.
3)The effects to elements from melting metal
Some metals, such as cobalt, nickel, chrome and so on, can corrade the element in high temperature melting state and affect the service life of element.
5.Packing details of silicon carbide rod heater
High quality furnace used silicon carbide rod heater


High quality furnace used silicon carbide rod heater

6.Why do you choose our silicon carbide rod heater?

1) Accept customized

2) Installation technical guidance

3) Inquiries answered within 24 hours

Quick answering  skype: leperm03  trademanager: cn1510854918

4) Pay for silicon carbide rod heater damaged in the transit
