Home > Products > Pillow Packing Machine > 2014 Popular Cookie Packing Machine
2014 Popular Cookie Packing Machine
- 80 Set / Sets per Month
- FOB
- T/T
You May Like
Product Details
Condition | New | Application | Food | |
Packaging Type | Bags, Film, Pouch, Other, Bags, Film, Pouch, Bag | Packaging Material | Plastic | |
Automatic Grade | Automatic | Driven Type | Electric | |
Voltage | 220V. 50 / 60Hz. | Power | 2.4/2.6/2.8KVA, 220V. 50 / 60Hz. 2.4/2.6/2.8KVA | |
Place of Origin | Shanghai, China | Brand Name | Huihe | |
Model Number | Cookie Packing Machine HP-250/320/350 | Weight | 800KG | |
Dimension(L*W*H) | 3770*(W)670*(H)1450mm | Certification | CE;ISO | |
After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
HP-250/320/350 Cookie Packing Machine
Feature
1. Double motor, double Panasonic transducer control and PLC controller,flexible bag length cutting, operator neednt to adjust the unloading working, saving time and saving films.
2, Buttoned human-machine screen, Chinese or English displaying, convenient and quick parameter setting.
3. Self diagnosis failure function, clear failure display.
4. High sensitivity optical electric color mark tracking, digital input cut position which makes the sealing and cutting more accurate.
5. Separate PID control to temperature, suitable for various packing materials.
6. Stopping the machine in selected position, no sticking to the knife and no waste packing film.
7. Simple driving system, reliable working, convenient maintenance.
8. .All the controls are achieved by software, convenient for function adjusting and upgrading.
Specification
Model No. | HP-250 | HP-320 | HP-350 |
Film width | Max.250mm | Max.320mm | Max.350mm |
Bag length | 65-190 or 120-280mm | 65-190 or 120-280mm | 65-190 or 120-280mm |
Bag width | 30-110mm | 50-150mm | 50-160mm |
Product height | Max.55mm | Max.55mm | Max.55mm |
Film roll diameter | Max.320mm | Max.320mm | Max.320mm |
Packing speed | 40-230bag/min | 40-230bag/min | 40-230bag/min |
Power supply | 220V 50/60Hz 2.4kw | 220V 50/60Hz 2.6kw | 220V 50/60Hz 2.8kw |
Machine size | 3770*670*1450mm | 4020*720*1320mm | 4020*770*1450mm |
Machine weight | 800kg | 900kg | 900kg |
Application
Suit for food, medicine, daily necessities,disposable product, hardware product, plastic
product,toy, industrial goods, industrial parts and car accessories industries.
Packing samples
After Sales Service:
1.Guaranty: One Year.
2.One set of consumable accessories will be provided with the machine.
3.Any question, you can mail/call us at any time. And our most experienced engineers are assigned to give consulting service, and always available for dispatching abroad.
4.All spare parts are always available for delivery.
5.Manual is in English.
Installation/ Training
If really dont know how to install and operate after showing the video and telephone instruction, you can ask for installation from us. It must be after shipment till the machine has arrived and factory must be ready equipped with all necessary requirements before booking installation. Our engineers will come to the site for the complete and final installation. During the installation session, a one-day training course will be provided to our customers about operation and maintenance procedure. The following costs should be paid by the buyer, including engineer's all local transportation, accommodation, and air tickets (round trip).
Payment terms
Choose the machine type → Goods delivery :(FOB,CIF,CFR,EXW) → Payment term :30% down payment as for ordering the machine (or 100 % payment that can save time ) → Confirmed the machine requirement → Based on your requested to producing machine→ Though video chat or send machine picture or directly come to inspection in our factory → Pay the rest of balance 70% → Arrange the shipment .(If need more technical support ,please contact our services )
