HP-250/320/350 Sample Packing Machine
Features
1. Double motor, double Panasonic transducer control and PLC controller,flexible bag length cutting, operator neednt to adjust the unloading working, saving time and saving films.
2, Buttoned human-machine screen, Chinese or English displaying, convenient and quick parameter setting.
3. Self diagnosis failure function, clear failure display.
4. High sensitivity optical electric color mark tracking, digital input cut position which makes the sealing and cutting more accurate.
5. Separate PID control to temperature, suitable for various packing materials.
6. Stopping the machine in selected position, no sticking to the knife and no waste packing film.
7. Simple driving system, reliable working, convenient maintenance.
8. .All the controls are achieved by software, convenient for function adjusting and upgrading.
Specification
| Model No. | HP-250 | HP-320 | HP-350 |
| Film width | Max.250mm | Max.320mm | Max.350mm |
| Bag length | 65-190 or 120-280mm | 65-190 or 120-280mm | 65-190 or 120-280mm |
| Bag width | 30-110mm | 50-150mm | 50-160mm |
| Product height | Max.55mm | Max.55mm | Max.55mm |
| Film roll diameter | Max.320mm | Max.320mm | Max.320mm |
| Packing speed | 40-230bag/min | 40-230bag/min | 40-230bag/min |
| Power supply | 220V 50/60Hz 2.4kw | 220V 50/60Hz 2.6kw | 220V 50/60Hz 2.8kw |
| Machine size | 3770*670*1450mm | 4020*720*1320mm | 4020*770*1450mm |
| Machine weight | 800kg | 900kg | 900kg |
