Help CenterCombined Grain Drying Machine JL-NOOT
Related Products
-
Dryers for Rice GrainUS$ 20,000 - 150,000MOQ: 1 Set -
Grain Handler Grain DryerUS$ 20,000 - 150,000MOQ: 1 Set
-
JL-NOOT Corn Dryer WholesaleUS$ 20,000 - 150,000MOQ: 1 Set
-
Grain Dryer Manufacturers /SuppliersMKR-NOOTUS$ 20,000 - 150,000MOQ: 1 Set
-
Steel Fibre Making MachineUS$ 85,000 - 90,000MOQ: 1 Set
Specifications
1)Multifunction ,not only can make continuous drying ,but also can achieve2)environmental and energy-efficient
main feature
1,The latest technology and revolutionary computerized touch screen controls.Controls are by way of a touch screen interface through a Programmable Logic Controller (PLC).:there are testing sensor transferred the the moisture and grain temperature to the computer control center,which are tested by testing sensor timely.
Through Computer program operations to control the following :
1)automatic control of raw grains input
2)hot air stove of accurately controlling for automatic
3)the control of hot air and temperature for different section
4)with temperature-based automatic moisture control.
4)the control of the air volume for output
5)Automatically adjusts dryer unloading speed to maintain grain discharge moisture.
6)Includes built-in control diagnostic,auto shutdown
MKR-N00T compared with other grain drying machines
|
Drying moisture ( %) |
energy consumption (coal)KG/H |
Hot air stove |
Stove control
|
Moisture test |
temperature |
System control way |
Tower insulation |
environment |
operation staff
|
MKR-N00T |
2-16 |
50-130 |
automatic |
Computer |
automatic |
automatic |
Controlled by computer |
Polyurethane sandwich panel
|
non- pollution |
1 |
Other |
1-4 |
100-250 |
manual |
nothing |
nothing |
manual |
nothing |
Single-color plate
|
severe pollution |
4 |
Specifications and technical parameters
Drying capacity(ton/24h) |
50 |
100 |
200 |
400 |
size(M) |
3.0×3.0 |
3.0×3.0 |
3.0×3.0×2 |
3.0×3.0×4 |
height(M) |
12 |
18 |
18 |
18 |
coal consumption(coal kg/h) |
40~80 |
40~100 |
50~130 |
100~400 |
installed capacity(KW_) |
40 |
60 |
70 |
120 |
Drying rate(%) |
2~16 |
|||
heating medium |
clean air |
|||
Temperature of hot air (°C) |
50-120 |
|||
Grain drying temperature(°C) |
30-55 |
|||
uneven of drying(%) |
< 2 |
|||
Breakage of drying(%) |
< 0.5 |
|||
heat consumption kj/kgH2O) |
5800 |
|||
