Specifications
Li-ion 26650 4000mAh batteryVoltage:3.6V
capacity:4000mAh
dimension:max 30*65mm(diameter*height)
cell weight:60g
we not only offer battery cells but also battery with cable,PCB and connector.
we have 18650 type, the capacity from 2000 to 3000mAh
for 26650, we main offer 4000mAh.
26650 4000mah flashlight battery
Specification |
li-ion battery |
Type |
Lithium-ion rechargeable cell |
Model |
26650 |
Nominal voltage |
3.7 V |
Nominal capacity |
4000mAh |
|
discharge from 4.2V to 3.0V at 0.2C mA |
Minimal capacity |
3900mAh |
Max charge current |
4000 mA 1C |
Charging method |
charge with constant current 1C to 4.2V, then charge with constant voltage 4.2V till charge current is less than 0.01C |
Discharge cut-off voltage |
3.0 V, the over-discharge detection voltage of PCM |
Operating environment |
Charging, 0°C ~ 45°C ; 65±20%RH |
Discharging, -20°C~60°C ; 65±20%RH | |
Storage environment |
-20°C~45°C |
storage for a long time(>3 months) and the storage condition shall be:<35°C;65±20%RH;3.7~3.9V | |
Cell Weight (Approx) |
60 g |
Cell Dimension (Max) |
according to customer demand |
Advantages:
1, High energy density
2, High working voltage for single battery cells
3, Pollution-free
4, Long cycle life
5, No memory effect
6, Capacity, resistance, Voltage, platform time consistency is good
7, With short-circuit production function, safe and reliable
8, Factory price& High quality
9, Good consistency, low self discharge
10, Light weight, small size
Features:
1, Longer storage life than NiMH Batteries
2, Light weight and higher energy density than any rechargeable battery
3, Installed IC chip will prevent the battery pack from over charge and over discharge.
It helps protect battery chemistry integrity and prolongs battery life.
4, Installed polyswitch will cut off power if battery discharge current more than 6.6Ah
5, Perfect for building up battery pack for medical equipment Back-up or EPS Emergency Power
6, Supply which requires compact size and lighter weight
7, The battery module is wrap by PVC
Others:
1, OEM orders are available
2, Superior quality and cost-performance ratio
3, Tags, plugs and connectors are available
4, We could design and produce the battery pack with plastic shell and assembly procession for customized configurations is available (we could design and develop Li-ion battery according to your product work performance & structure apprearance)
if you have any requirments please feel free to contact with us,thank you!
