Mineral Water Filling Machine
- 100 Set / Sets per Month
- SHANGHAI
- T/T Credit Card
- Cheapest Automatic Bottle Blowing Machine Prices/factory price automatic bottle shrink wrapping machine
- PET bottle making machine/nice plastic bottle making machine price/high quality plastic bottle blowing machine
- Top quality china automatic machines to make plastic bottles/bottle blowing machinery/Pet Bottles Blowing Machine 750ml
- Chinese PET water bottle blowing machine/equipment / automatic bottle Blowing machinery
- Low price Beverage drinking PET bottle blowing machinery/fully automatic pet bottle blowing machine
- high quality bottle blowing machine/automatic shrink wrapping machine/water bottle blowing machine
Product Details
Condition: | New | Application: | Beverage | Packaging Type: | Bottles |
Packaging Material: | Plastic, Glass | Automatic Grade: | Automatic | Driven Type: | Electric |
Voltage: | 380V | Power: | 6.8KW | Place of Origin: | Jiangsu, China |
Brand Name: | DINGSHUN | Model Number: | XGF32-32-10 | Dimension(L*W*H): | 3800*2200*2300mm |
Weight: | 5500KG | Certification: | CE ISO | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Mineral Water Filling Machine1. Full Automatic
2.PLC controlling
3. 14000bph water fillling monobloc
4. CE ISO
Welcome your visit to Zhangjiagang Dingshun Machinery Factory!
Our company specialized in providing complete beverage line machinery for water,juice, carbonated beverage,alcohol and oil.
Mineral Water Filling Machine
Main Features
1).This Mineral Water Filling Machine is used to fill PET bottle pure water, mineral water,distilled water and other non gas beverage.
2). This Mineral Water Filling Machine has the functions of bottle washing, water filling, and bottle capping. This design reduce the time of water contact with outside. It improve the sanitation condition, increase the production capacity and economic efficiency.
3). It adpots hanging type conveying bottle structure to make changing different bottle sizes with less time and more convenient.
4).This water filling machine use high quality food grade stainless steel material. All the material contact with water is Stainless Steel 304 (& stainless steel 316L according to customer's demands).
5).The whole machine is equipped with advanced PLC controlling system. Key electric elements is from international well-known brand such as MITSUBISHI, OMRON,SCHNEIDER.
6). Filling Capacity 2,000bph to 20,000bph for your choice.
7). This Mineral Water Filling Machine model No. XGF32-32-10 filling capacity is 12,000-14,000bph.
XGF series bottled mineral water filling machine model and related information
Model: | XGF8-8-3 | XGF12-12-4 | XGF14-12-5 | XGF18-18-6 | XGF24-24-8 | XGF32-32-10 | XGF40-40-12 |
Capacity (500ml based) | 2000-3000BPH | 4000BPH | 5000BPH | 8000BPH | 10000BPH | 12000-14000BPH | 16000-18000BPH |
Suitable bottle : | Round bottle or square bottle | ||||||
PET bottle: (mm) | (Bottle Diameter):φ50-.φ110mm (Height):150-340mm | ||||||
Suitable cap specification | PE screw cap | ||||||
Filling precision: | ≤±5mm | ||||||
Filling pressure:(MPa) | ≤0.4Mpa | ||||||
Machine power | 3.13 | 3.75 | 4.4 | 5.2 | 6.2 | 6.8 | 7.8 |
Machine size:(mm) | 1900*1500*2300 | 1900*1500*2300 | 2150*1650*2300 | 2400*1965*2300 | 2680*2200*2300 | 3800*2200*2300 | 4250*3000*2300 |
Weight: (kg) | 1500 | 1800 | 2100 | 3500 | 4500 | 5500 | 6800 |
This mineral water filling machine parts picture is as below
Rinsing Filling Capping
Production on spot
Machine Packing and Loading
Our factory and workshop
Welcome your visit to our factory and build good business relationship with us!
