1. Automatic Bottle Unscrambler machine2. PLC controlling
3. 15000bph bottle unscrambler
4. Bottle sorting machine
Welcome your visit to Zhangjiagang Dingshun Machinery Factory!
Our company specialized in providing complete beverage line machinery for water,juice, carbonated beverage,alcohol and oil.
Automatic Bottle Unscrambler Machine
This automatic bottle unscramber machine is suitable for unscrambling disorder polyester bottles, make them order and in one line, then discharge them by vaccum conveyor.
It has the features: PLC program controlling; digit speed; automatic high speed operation, easy to combine with all kinds of filler or filling production line.
1.Technical parameter:
1.1 Model:LP-18
1.2 Bottle location number: 18
1.3 Theory capacity: 12,000bph to 15,000bph.
1.4 The highest capacity: 15000bph
1.5 Pressure of raw air: 0.7Mpa
1.6 Air consumption: 1.5M3/min
1.7 Applicable plastic bottle: diameter50-90mm, bottle height: 150-290mm
1.8 Main motor power: 2.2KW
1.9 Elevator power: 0.75KW
1.10 Dimension: Φ2650X2340
1.11 Weight: 4200KG
Automatic Bottle Unscrambler Features:
2.1 The main motor speed reducer applies torque limit mechanism to avoid harming the machine when trouble happens.
2.2 Twice push rowing bottle mechanism is used to ensure every bottle location has bottle which apparently prompts bottle output efficiency.
2.3 Bottle handling air conveyor prevents bottles from dropping down when in transportation.
2.4 Damaged bottles shall be rejected according to the reject mechanism.
2.5 This machine is equipped with blocking bottle detector. It will stop and alarm when bottle blocks.
2.6 No-bottle detector will send signal to elevator immediately when the bottle quantity is few and elevator shall supply bottles automatically.
2.7 Photoelectric switch is installed on the air conveyor to control the unscramble machine.
2.8 Bottle unscramble machine has oil mouths which make the gear, bearing and cam lubrication conveniently.
2.9 Main electrical appliance (Inverter, PLC, Photoelectric switch, Relay) is from MITSUBISHI,OMRON,SIMENS and so on
2.10 Air system uses TAIWAN AIRTAC.
Automatic Bottle Unscrambler Machine Picture
