Thermostatic faucet1.brass body
2.vernet sensor thermostatic faucet
3.tempreture function all in one
4.new design
Thermostatic faucet
1.brass body
2.vernet sensor thermostatic faucet
3.tempreture function all in one
4.new design
“THERMOSTATIC” brife intruduction
When the inlet waters’ temperature changed or the water pressure changed,the thermostatic taps will adjusted by themselves voluntarily to keep the outlet water temperature on your fixed temperature advanced(the restless scope is ±1°C).Thermostatic,which is the terminal outlet water temperature.But the“THERMOSTATIC” of some heatermachine factories means to control the heating temperature of the hot water.
Main features and specifications:
1.brass body
2.brass handle
3.vernet sensor for the thermostatic faucet
4.latest new version
5.38 °C stop function
Cartridge test data:
Work mpa |
0.05-1Mpa |
The best Mpa |
0.1-0.5Mpa |
Cold water temperature |
5-29°C |
Hot water temperature |
50-80°C |
temperature range |
20-50°C |
Set security button temperature |
38°C |
Cold water to test its |
Cold water from five seconds for the water flow rate dropped to measures 1.9 per minute, Out the flow of water≤150ml, leaving water temp≤49°C |
Life tests |
CSA B125-98 ASSE 1016(≥100,000cycle) |
Water temperature automatically regulate sensitivity |
As the temperature and pressure variation20%, Water temperature changes≤2°C. As the pressure constant, Hot water the temperature change50-80°C, Cold temperature4-29°C, And out of the water temperature≤2°C |
Standards |
CSA B125-98 ASSE 1016 EN 1111 AS-4032.1 QB2806-2006 |
Packing : one piece in one inner box , 12pcs in one carton .
Guanrantee :Three years
OEM SERVICE ACCEPTED
