er14335m LiSOCl2 rechargeable 2/3AA 3.6v battery
Items |
Parameters |
Battery Model |
ER14335M |
Nominal Voltage |
3.6V |
Nominal Capacity |
1350mAh |
Standard Discharge Current |
3mA |
Max. Continuous Discharge Current |
300mA |
Max. Pulse Discharge Current |
500mA |
Max. Dimension(Diameter*Height) |
14*33.5mm |
Discharge Cut-off Voltage |
2.0V |
Weight |
13g |
Operating Temperature |
-55~85℃ |
Self-discharge Rate |
1% |
Storage Condition |
≤30°C & ≤75%RH |
Closer Look:
Key Features
- High Energy Density
- High single cell voltage
- Stable operating voltage
- Hermetic glass to metal sealing technical
- Restricted for UL, UN38.3 and ROHS
- Be easy to integrate into the device to use
- Wide Operating temperature range from -55 ° C to +85°C.
- Suited for long-term use with low current :long storage life (10 years) and low self-discharge (1 % or less per year)
- For operation at low current levels with long stands intermittent discharge with medium current level provided. The average is not below the active current level.
Main Applications
- Utility meter (water, electricity, gas meter and AMR)
- Alarm or security equipment (smoke alarm system and detector)
- GPS system, GSM system
- Real-time clock, Car electronics
- Digital control machine
- Wireless and other military equipment
- Remote monitoring systems
- Signal lights and the post indicator
- back-up record power, Medical equipment
1. Precautions and Safety Instructions of Lithium Battery Li-SOCI2
Please pay attention to followings in case of batteries will have leakage, heat etc.
♦ Do not connect the positive and negative terminals of the battery.
♦ Do not place battery into fire.
♦ Do not weld directly battery long time.
♦ Do not recharge and force-discharge battery.
♦ Do not combine batteries in series or parallel by oneself.
♦ Do not reverse the positive and negative terminals
♦ Do not swallow and discard.
♦ Stop immediately use it when serious heating or leakage.
♦ Do not heat/use the battery beyond the permitted temperature range.
♦ Before using our batteries, please read the manual Carefully or contact us.
2. Storage of Lithium Battery Li-SOCI2
♦ Stored battery in clean, dry and cool circumstances.
♦ Storage temperature will be ≤30℃ while storage Humidity will be ≤75% RH.
♦ The storage temperature or humidity too high(low) will increase battery's self-discharge rate and reduce battery's storage life.
General Electronics Battery Co., Ltd. is a Sino-American jointventure company integrates R&D, manufacture and sales Fortune Global 500 lithium battery customers special supplier Over 1000 different sizes and capacities of batteries
We participate in a variety of trade fairs twice every year .On Electronics Show we discuss with customers
about our products and help them solve questions face to face.We have established contacts with many potential buyers from other places as America,Australia, Belgium, Israel,Germany,the Netherlands, Canada etc.
1. Q: What is nominal capacity?
A: Nominal capacity is measured at 23±2℃,discharge at standard constant current until 2.0V cut off.
2. Q: What is nominal voltage ?
A: Micro-current discharge platform voltage reference values has 3.0V to do with battery chemistry system and has nothing to do with the battery model.
3. Q: What influences battery capacity?
A: Battery capacity depends on temperature ,discharge currents and cutoff voltage.
4. Q: What is maximum continuous current?
A: At 23±2℃ the battery can discharge at least the max continuous discharge value which rated capacity 50% can permit.
5. Q: What is maximum pulse discharge current?
A: At 23±2℃,battery discharge duration for 3 seconds and stand 27 seconds, it can discharge at least the max pulse discharge value which rated capacity 50% can permit.
