Home > Lights & Lighting > LED Interior Lighting > LED Panel Light > RGB LED Matrix Pannel Flexible LED Display

RGB LED Matrix Pannel Flexible LED Display

RGB LED Matrix Pannel Flexible LED Display thumbnail-3

RGB LED Matrix Pannel Flexible LED Display thumbnail-4

RGB LED Matrix Pannel Flexible LED Display thumbnail-5

RGB LED Matrix Pannel Flexible LED Display thumbnail-6

RGB LED Matrix Pannel Flexible LED Display photo-1

RGB LED Matrix Pannel Flexible LED Display photo-2

RGB LED Matrix Pannel Flexible LED Display photo-3

RGB LED Matrix Pannel Flexible LED Display photo-4

RGB LED Matrix Pannel Flexible LED Display photo-5

RGB LED Matrix Pannel Flexible LED Display photo-6

US$ 0.5 - 55 MOQ: 5 Pieces

Key Specifications

Get Latest Price

Input Voltage(V):

Lamp Power(W):

Color Temperature(CCT):

Other, full color

Contact Supplier Request Quote Chat Now

Shenzhen Shining Future LED Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Input Voltage(V) 5

Lamp Power(W) 30

Color Temperature(CCT) Other, full color

Lamp Body Material Aluminum

IP Rating IP33

Model Number WS2812 LED Pixel Screen

RGB LED Matrix pannel Flexible LED Display

8x8,16x16,32x8 Flexible LED Pixel Screen RGB Display,DC5V WS2812B SMD 5050 Full Color Indoor LED Advertising Display Screen

Come on,sfleds is the best choosing for you!

Description:

Pixels WS2812 led digital flexible panel light(WS2811 IC controlled)

Work with the programmable SD controller(not included), it can make flexible LED screen

Arduino IC Digital Addressable Dream Color RGB LED Strip

Arduino compatible.You can control the strip by your programmable arduino.

Technology advantages

The WS2812 SMD5050 RGB LED, every led built-in(embedded) an WS2811 IC,, therefore every one led lignting effect can be control, every rgb led is digital addressable.

Easy installation

Every one LED lamp can be arbitrary cut off, good flexibility, easy installation, can be arbitrary bending.

Dream color lighting

Match use controller can appear colorful curtain-up/ flow water/raindrop/jump flash and so on hundreds of lighting effect,

you can also edit animation effect by Coreldraw/Flash/LedEdit software.

Application

Making led screen, led wall, advertising board. Apply to hotel, KTV, bars, advertisement company, decoration company, the city lighting project, entertainment and leisure places lighting.

1. Emitting color: pixel RGB , IC WS2812

2. Work voltage: DC 5V

3. Power: 0.3W/pixel

4. waterproof level: Non-waterproof

5. Working mode: external controller Arduino compatible.

6. Connection: VCC: RED; GND:BLACK; DAT:GREEN

These panels are normally used to make video walls, you can see them on the sides of busses and bus stops, to display animations or short video clips. They have 256 bright RGB LEDs arranged in a 16x16 grid on the front. On the back there is a PCB with 1 pairs 3 pin connectors ( non-waterproof).

SPECIFICATIONS:

Model	sfleds-FP-2812
DC Power	DC5v.76.8W
LED Type	SMD5050 RGB
IC chip	WS2811
LED Qty	16*16
Size	170*170mm
IP Rank	non-waterproof
Warranty	2years

CONTROLLING:

This panel can be controlled by SD card controller, as it controlled by WS2811 IC chip. It also can work with DMX 512 system,but it will use a dmx decoder between the dmx controller to the panels.

Show pictures:

16*16 Digital RGB LED Matrix is consist of WS2812B RGB LED. WS2812B is a 5050 components that integrate control circuit and RGB chip in a package.

The LED Matrix are placed 16 Pixels each line, and there are 16 lines on each panel. The space between each pixel is 1cm.

Feature:

PIN Function:

No.	Symbol	PIN	Function Description
1	+5V	Power	5V power supply
2	DIN	Data Input	Input the control signal
3	GND	Ground	Earthing
4	DOUT	Data Output	Output the control signal, and connect to next panel’s DIN

RGB Parameters

Color	Model	Wavelengthnm	luminous intensitymcd	operating voltage
Blue	13CBAUP	465-467	180-200	3.0-3.4
Green	13CGAUP	522-525	660-720	3.0-3.4
Red	10R1MUX	620-625	390-420	2.0-2.2

Data Transfer (TH+TL=1.25µs±600ns)

T0H	Code 0, High level	0.4µs	±150ns
T1H	Code 1, High level	0.8 µs	±150ns
T0L	Code 0, Low level	0.85µs	±150ns
T1L	Code 1, Low level	0.45 µs	±150ns
RES	Low level	>50µs

Timing Waveforms:

Input Code:

Connection Method:

Specification

LED Quantity	256
IC Type	WS2812 (IC Built in LED)
Wattage	78.6W/M
Pixel/m	16*16
PCB Width	16*16cm
Length of cable	100mm
Working Voltage	DC 5V
PCB Color	black
Light Color	Multi-Color, digital RGB,Every LED individual Contro
