Addressable Led Strip Light SK6812 RGBW/RGBWW ip 67 Led Strip Light

Addressable Led Strip Light SK6812 RGBW/RGBWW ip 67 Led Strip Light thumbnail-1
Addressable Led Strip Light SK6812 RGBW/RGBWW ip 67 Led Strip Light thumbnail-2
Addressable Led Strip Light SK6812 RGBW/RGBWW ip 67 Led Strip Light thumbnail-3
Addressable Led Strip Light SK6812 RGBW/RGBWW ip 67 Led Strip Light thumbnail-4
Addressable Led Strip Light SK6812 RGBW/RGBWW ip 67 Led Strip Light thumbnail-5
Addressable Led Strip Light SK6812 RGBW/RGBWW ip 67 Led Strip Light thumbnail-6
Addressable Led Strip Light SK6812 RGBW/RGBWW ip 67 Led Strip Light photo-1
Addressable Led Strip Light SK6812 RGBW/RGBWW ip 67 Led Strip Light photo-2
Addressable Led Strip Light SK6812 RGBW/RGBWW ip 67 Led Strip Light photo-3
Addressable Led Strip Light SK6812 RGBW/RGBWW ip 67 Led Strip Light photo-4
Addressable Led Strip Light SK6812 RGBW/RGBWW ip 67 Led Strip Light photo-5
Addressable Led Strip Light SK6812 RGBW/RGBWW ip 67 Led Strip Light photo-6
US$ 3.94 - 15.36 MOQ: 100 Meters
Key Specifications
Get Latest Price
LED Light Source:
SMD5050
Type:
Flex LED Strips
Input Voltage(V):
DC5V
Contact Supplier Request Quote Chat Now
Shenzhen Shining Future LED Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source SMD5050
Type Flex LED Strips
Input Voltage(V) DC5V
Lamp Power 7.2W/M
Lamp Luminous Flux(lm) Different based on different color
Color Temperature(CCT) 2700K-7000K
Working Temperature(℃) -20, 50
Working Lifetime(Hour) 50000
Lamp Body Material Copper
Certification CE
Emitting Color Changeable
Place of Origin Guangdong, China
Brand Name sfleds
Model Number Light Strips

Addressable led strip light SK6812 RGBW/RGBWW ip 67 led strip light

Product Specification:

Description

Built-in driver IC SK6812 RGBW

LED Type

5050 SMD

LED Quantity

30/60/144LED/m

Each LED separately control

Grey scale

   256/color

Working Voltage

  DC 5v

Beam Angle

120 degree

FPC Color

BLACK/WHITE

Available Color

Full color

IP Grade

IP20/65 Waterproof

Operating Temperature

-20~+50 degree

Packing

5 meter





LED source :5050SMD RGBW built-in SK6812 chipset

Voltage(DC):5V

Power: 144LEDs/meter -------43.2W / Meter

             72LEDs/meter ---------21.6W / Meter

             60LEDs/meter ---------18W / Meter

             30LEDs/meter ---------9W / Meter

LED type :SMD5050

IC type :SK6812

LED/per meter:30, 60,72, 144leds/Meter (each LED is separately controlled)
IC/per meter: 30, 60,72, 144IC/Meter (1 IC drives 1 led chip)

Pixel /per meter :30, 60,72, 144Pixels/Meter
Grey Grade: 256

Color:  RGBW (WW 2700-3000K ; CW 6000-6500K)

PCB color:White / Black available


Addressable led strip light SK6812 RGBW/RGBWW ip 67 led strip light

Newest  Design: sk6812 RGBW /SK6812WWA /SK6812WS/NW/BW/SK6812 P8 are available.
And APA102 RGBW Digital LED Strip:30/32/48/60/72/144leds per meter available,each 3 Wire output:Data,GND,Anode,5050 SMD Built-in IC,White/ Warm White/ Nature White /Cool White 4 kinds color available.Besides the digital RGBW led strip can be APA104,WS2801,WS2811 optional.







Addressable led strip light SK6812 RGBW/RGBWW ip 67 led strip lightAddressable led strip light SK6812 RGBW/RGBWW ip 67 led strip lightAddressable led strip light SK6812 RGBW/RGBWW ip 67 led strip lightAddressable led strip light SK6812 RGBW/RGBWW ip 67 led strip light



Addressable led strip light SK6812 RGBW/RGBWW ip 67 led strip light

 Addressable led strip light SK6812 RGBW/RGBWW ip 67 led strip lightAddressable led strip light SK6812 RGBW/RGBWW ip 67 led strip lightAddressable led strip light SK6812 RGBW/RGBWW ip 67 led strip lightAddressable led strip light SK6812 RGBW/RGBWW ip 67 led strip lightAddressable led strip light SK6812 RGBW/RGBWW ip 67 led strip light

Controller proposal



Addressable led strip light SK6812 RGBW/RGBWW ip 67 led strip light



our service



1) ODM+OEM Service offered
2) Overseas Agency is opened
3) Provide full support in lighting solutions for customer request.
4) More quantity, more discount



Pacaging&shipping



Addressable led strip light SK6812 RGBW/RGBWW ip 67 led strip lightAddressable led strip light SK6812 RGBW/RGBWW ip 67 led strip light
