Nc Studio Control 4Axis CNC Milling Machine CNC Router 3D Wood Machine with Multi-rotary
Detailed Features:
1. CC-MS3020K-8 model machine is the 3D , 4 axises CNC Router Machine, with 8 Rotaries and 8 spindles, which can work at the same time or independently, and every one's max effective working area is 225 mm(diameter) by 3000mm(length).
2. Two Functions, one is Plane Table for Plane material Cutting and Engraving. The second funtion is 8 Rotaries for do Cylinder / Round Material Engraving and Milling.
If you With Scanner or designed photo, it can do any 3D Engraving and 2D Engraving .
3. Whole machine is welded with seamless steel structure, the stability is excellent, not easy to be deformed.
4. Adopting advanced 5sets high-torque YASAKWA servo motor and 3D & 4Axis NC studio control system .
5. X and Y axes adopt rack and pinion transmission, faster working, higher efficiency and low cost. Z axis adopts Germany-made ball-screwand TaiwanHiwin H30 square orbit, with high precision and longevity.
6. Advanced file pretreatment function can correct the error in the files and is compatible with the process codes of multiple national and international software.(such as Mastercam, Type3,Arecam) .
7. Advanced file pretreatment function can correct the error in the files and is compatible with the process codes of multiple national and international software.(such as Mastercam, Type3,Arecam) .
8.High soft, famous brand electric cables, with high Abrasion, fold, high temperature , acid and alkali resistant .
9. We will provide you several kinds software for free, with English and Multilingual versions(CAD/CAM designing software e.g. Type 3/Artcam/etc.). Also you can get the perfect picture storage with thousands 2D and 3D designs, and some kinds of spare parts, work piece fixtures.
10. Has the function of re-carving after break point and power failure.
11. Perfect after sale service, timely reply to your any question, professional instructions for the machine, software and parts' using.
12. Any workstage is strictly processed according to Euro CE Quality Standard and ISO Quality Standard . Any set CNC Router will be done at least 72 hours careful testing and checking, from small part to the whole machine . After any part's quality inspection, finishing Basic maintenance measures, then the machine can be packaged by the specialized workers for transport.
13. Our company has powerful strength in metal Machining. In order to make sure every detail's high quality level, most of the machine's metal parts are made by our own Machining Center imported from American .
Technical Parameter:
Model |
CC-MS3020K-8 |
|
Description |
Parameter |
Optional parameter |
X,Y Working Area |
2000*3000mm |
|
Z Working Area |
300mm |
|
4th rotary axis max diameter |
225mm |
125mm, 200mm,150mm |
Flat Table Size |
2140*3000mm |
|
Resolution |
0.03mm |
|
Lathe Structure |
Seamless welded steel structure |
|
X,Y Structure |
Rack and pinion, gear drive, Big Size Taiwan Hiwin square guide rails |
|
Z Structure |
Germany-made rolling ball screw, Big Size Taiwan Hiwin square guide rails |
|
Max. Idling Speed |
40m/min |
|
Spindle |
Water Cooling Spindle 2.0KW |
1.5kw |
Spindle Speed |
0-24000r/min, variable speed |
|
Working Voltage |
AC380V/50Hz |
220V |
Motor and driver |
Japan Yaskawa Servo |
|
Command |
G code (HPGL, U00, mmg, plt) |
|
Operating System |
Original Version Nc Studio control system |
|
Diameter of Cutter |
φ3.175-φ12.7 |
|
Dust-collect Function |
Yes |
No |
Work Holding |
Clamps, Chucks |
|
Net Weight |
2200KG |
|
Other Parts:
Samples:
Package:
