Home > Products > Fiber Disc > 7" star hole abrasive fiber disc
7" star hole abrasive fiber disc
- 5000 Piece / Pieces per Month
- Shanghai
- T/T
- sponge grinding wheel for stainless steel
- diamond polishing pad for marble and granite
- abrasive Sheet Roll
- High precision electric spindle CBN grinding wheel grinding rod 20Cr carburizing quenching inner circular grinding machining
- Customized processing of carbon fiber with irregular shaped steel sand grinding head profile for rapid prototyping with good roughness
- Customized 190mm long electroplated diamond sand needle SDC120 # for drilling wood with a handle diameter of 2.5mm
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | bowei/OEM | Model Number: | abrasive fiber disc |
Type: | Abrasive Disc | Size: | 4",4.5"5",6",7" |
Product Description
Specifications
1,abrasive fiber disc for polishing marble,non-ferrous2,D100,D115,D125,D150,D180
2,Supply OEM
Trademark: XTRA POWER brand/OEM
Product Name: 7" star hole abrasive fiber disc
1>Description:
1) Specification: Diameter: 4", 4.5", 5", 6", 7" (100mm - 180mm)
Thickness: 0.8mm-1.2mm
Hole pattern: round ,cross,star
Hole diameter:16 or 22mm
Coating: close
2) Material: aluminum oxide/ silicon carbide/zirconia
3) Grit : 16# - 320#
4) Color: red / black /blue
5) Backing : Fiber paper
6) Datasheet:
Aluminium Oxide Fiber Disc | ||||||
Art.No. | Size (mm) | Grit | Max.PRM | Carton Qty (piece) | Carton Size (cm) | Gross/Net Weight (kg) |
FDA10016 | 100x16 | 16-320 | 15200 | 1200 | 44x33x16 | 19/17 |
FDA11522 | 115x22 | 16-320 | 13300 | 1000 | 26x26x39 | 22/20 |
FDA12522 | 125x22 | 16-320 | 12200 | 600 | 28x28x23 | 19/17 |
FDA15022 | 150x22 | 16-320 | 10200 | 600 | 33x33x23 | 22/20 |
FDA18022 | 180x22 | 16-320 | 8500 | 400 | 39x39x16 | 22/20 |
Silicon Carbide Fiber Disc | ||||||
Art.No. | Size (mm) | Grit | Max.PRM | Carton Qty (piece) | Carton Size (cm) | Gross/Net Weight (kg) |
FDC10016 | 100x16 | 16-320 | 15200 | 1200 | 44x33x16 | 19/17 |
FDC11522 | 115x22 | 16-320 | 13300 | 1000 | 26x26x39 | 22/20 |
FDC12522 | 125x22 | 16-320 | 12200 | 600 | 28x28x23 | 19/17 |
FDC15022 | 150x22 | 16-320 | 10200 | 600 | 33x33x23 | 22/20 |
FDC18022 | 180x22 | 16-320 | 8500 | 400 | 39x39x16 | 22/20 |
Zirconium Oxide Fiber Disc | ||||||
Art.No. | Size (mm) | Grit | Max.PRM | Carton Qty (piece) | Carton Size (cm) | Gross/Net Weight (kg) |
FDZ10016 | 100x16 | 16-320 | 15200 | 1200 | 44x33x16 | 19/17 |
FDZ11522 | 115x22 | 16-320 | 13300 | 1000 | 26x26x39 | 22/20 |
FDZ12522 | 125x22 | 16-320 | 12200 | 600 | 28x28x23 | 19/17 |
FDZ15022 | 150x22 | 16-320 | 10200 | 600 | 33x33x23 | 22/20 |
FDZ18022 | 180x22 | 16-320 | 8500 | 400 | 39x39x16 | 22/20 |
2>Features:
1,High surface removing rate.
2,Wear-resistant ,durable.
3,Good anti-clogging.
4,Good capacity of heat releasing.
3>Application:
For polishing hard wood,furniture, stainless steel ,weld, hard wood , non-ferrous metal , weld trimmings, lacquer, paint, stone,and automobile.
4>Picture shows:
1,Aluminum oxide fiber disc
2,Carbide silicon fiber disc
3)Zirconium oxide fiber disc
5>Production lines shows:
1,Fiber disc production line
2,Velcro disc production line
6>Packing:
1)25pcs in shrink;
2,500pcs in a carton, or according your demand.
7>Guide to storage
The product should be stored in the dry and ventilating storehouse, and avoid moisture and fire, and should be kept in the package before use. The date of storage is 5 years.
8>Our customer:
9>Company profile:
Yangzhong Bowei Abrasives Co., Ltd. is a manufacturer of coated abrasive final products. Our main products cover fiber discs, velcro discs, abrasive cloths, abrasive paper, abrasive belts, self-adhesive products, abrasive paper, abrasive flap discs, industry non-woven products, etc. suitable for surface treatment work of moving rust and scar, grinding, polishing, fining and cleaning, etc.
Offer OEM Service
10>Contact us:
Warmly welcome to contact with us.
Evan
Tel:0086-15995825309
Website: http://bwabrasive.en.china.cn
Contact Us
- Yangzhong Bowei Abrasive Co., Ltd.
- Contact nameVanilla HO
- Phone0086-511-88229337
- AddressHuangshantao Industrial Park, Xinba Town
