Help CenterTop Quality Decorative PVC Ceiling Tiles
Related Products
Specifications
High shinky surface ,smooth, without gap when concatenated.The variety of colors and patterns.High intesity,resist corrode ,longPvc ceiling is the best choice as the suspended,dry wall partition because of 100% quality guarantee,thermal insulation,elegant
|
A. Specifications: MM
|
Length x Width:
|
595X595,595X1195,600X600,603X603, 605X605,603X1212, 610X1220(2′X4′) |
Thickness: |
7.0,7.5, 8.0,8.5,9.0,9.5,12,12.5 |
|
Specifications Tolerance |
Length: +_ 1.0MM, Width : +_ 1.0MM , Thickness : +_ 0.5MM |
|
Packing |
6/8/10 pieces per carton with shrink wrap bag and importer trade mark printed on the carton strip. |
|
Max loaded details |
740/1350/1400 cartons, 3239.40-4032 squre meters, 23.5 Tons , loaded in one 20′FCL |
|
B. Technical Data |
1.Weight / sqm: 7.0 MM: 5.5KGS. 7.5MM: 5.7KGS.8.0MM:5.9KGS. 8.5MM:6.2KGS.9.0MM:6.8KGS.9.5MM:7.1KGS.12MM:9.2KGS.12.5MM:9.5KGS |
|
2.Fire resistant property |
No- flammable B1 in accordance with Chinese Standard GB8624-1997 |
|
3.Lengthways & Lateral Ruptures Load |
7MM: >110N. 8.0MM : > 120N . 9.0MM: >140 N.
|
|
Installation |
Match with Top quality T-32/38 grids with 0.30-0.45MM thickness. |
|
Properties: The top quality pvc laminated gypsum ceiling tile with best aluminum foil backing is of thermal insulation, fire resistant, moisture resistant, no deviation, elegant, economic, environmental and easy installation, as the suspended ceiling tile and dry wall partition. | ||
Length:6m,5.95m,4m,3m or customized
Width:5cm,10cm,15cm,18cm,20cm,24cm,25cm,28cm,30cm,
40.6cm,59.5cm
Thickness:0.5cm,0.6cm,0.7cm,0.75cm,0.8cm,0.85cm,0.9cm,1cm,1.2cm
It can be processed by drilling, sawing, nailing, planning and bonding and be in hot-forming, hot-bending and hot-folding and be welded and bonded with supplementary materials
High shinky surface ,smooth, without gap when concatenated
The variety of colors and patterns
High intesity,resist corrode ,long life time,simple to maintain
Healthy and enviroment,
