Specifications
Dump Trucks-HOWO with good qualities and competitive prices,prompt deliveryHOWO-A7 heavy duty truck ----Superb art in domestic auto field, Full expression of heavy duty truck concept. Delicate design, excellent technology, which will dazzle you as groundbreaking works.
Comfortability, safety, reliability and intellectualization up to the international level. Low fuel consumption—the most economical choice nationwide.
The style of HOWO-A7 comes from famous Italian engineers, adopted European classic style and showing the latest international developing trend.
HOWO-A7 contains all types of vehicle, including tractor, lorry, tipper, concrete mixer and other special purpose vehicles.
Drive types: 4×2, 6×2, 6×4, 8×4, etc.
Engine power range: 270PS—460PS
Weight Parameter |
Complete Vehicle Kerb Mass(kg) |
11940 |
|
Maximum authorized total mass (kg) |
25000 |
||
Maximum authorized towed total mass(kg) |
|||
Dimension Parameter |
External Dimensions(mm) |
Length |
7445 |
Width |
2496 |
||
Height |
3490 |
||
wheelbase(mm) |
2975+1350 |
||
Minimum Ground Clearance(mm) |
315 |
||
Performance Parameter |
Maximum Speed(km/h) |
78 |
|
Economical Speed(km/h) |
58 |
||
Maximum Gradeability(%) |
35 |
||
Turning diameter(m) |
14 |
||
Recommended Configuration |
Engine |
Engine Type |
D10.27-40,D10.30-40 |
Rated power(kW)/Rev(r/min) |
196/1900,209/1900 |
||
Maximum Torque(N*m)/Rev(r/min) |
1190/1200-1500,1290/1200-1500 |
||
Transmission |
HW10,HW12,HW16 |
||
Clutch(mm) |
430 |
||
Rear Axle |
Type |
AC16 |
|
Speed Ratio |
4.77,5.45 |
||
Fuel Tank(L) |
300 |
||
Chassis Cross-section(mm) |
300 |
||
Suspension(Front,Back) |
10/12,10/- |
||
Tyre |
11.00-20 18PR,11.00R20 18PR,12.00-20 18PR,12.00R20 16PR |
||
