Help CenterHowo Garbage Truck, Compression / Refuse Collector
Related Products
-
HOWO SINO 8x4 Oil Tank Truck FOR HOT SALEUS$ 32,000 - 50,000MOQ: 1 Set -
Water Tank Truck for Hat SaleUS$ 32,000 - 50,000MOQ: 1 Unit
-
Sinotruk Howo 4x2 Fire Truck ZZ1167M4617C5US$ 30,000 - 60,000MOQ: 1 Unit
-
Sinotruk Howo 4x2 Fire Truck ZZ1167M3817C5US$ 30,000 - 60,000MOQ: 1 Unit
-
Howo Fire Truck With Good Quality and Best PriceUS$ 30,000 - 60,000MOQ: 1 Unit
Specifications
garbage compactor truck
dustbin can lift by the hydraulic system
the garbage box is a hermetic box
large capactiy easy con
(QUALITY PARAMETERS): | ||||
|
VEHICLE QUALITY (kg) |
10000 |
TOTAL MASS (kg) |
16000 |
|
|
RATED LOAD MASS (kg) |
5805 |
BOUNDARY DIMENSIONS(mm) |
8890×2495×3100 |
|
(CHASSIS PARAMETERS): | ||||
CHASSIS MODEL |
DFL1160BX4 |
TYRE MODEL |
10.00R20/9.00R20 |
|
WHEELBASE (mm) |
4500 |
TREAD(front/rear)mm |
1880/1860 |
|
FRONT SUSPENSION (mm) |
1430 |
REAR SUSPENSION(mm) |
2660 |
|
|
APPROACH/DEPARTUREANGLE(°) |
20/17 |
MIN.AROUND CLEARANCE (mm) |
250 |
|
(ENGINE PARAMETERS): | ||||
MODELS |
ISDe 210 40 |
MANUFACTURE |
Dongfeng Cummins |
|
|
MAX.POWER(kw) |
155 |
MAX.TORQUE (N.m) |
800 |
|
|
BORE/STROKE(mm) |
6-107×124 |
DISPLACEMENT(ml) |
6700 |
|
FUEL TYPE |
diesel |
|
|
|
(EQUIPMENT PARAMETERS): | ||||
|
RATED LOAD CAPACITY(m³) |
14 |
FILL CAPACITY(m³) |
14 |
|
|
HYDRAULIC PUMP MODEL |
CBG2080/ 2032-BFPL |
HYDRAULIC VALVE MODEL |
Q130/A5-F7SN,(GALTECH) |
|
|
WATER PUMP MODEL |
/ |
MOTOR MODEL |
/ |
|
(PERFORMANCE AND OTHER PARAMETERS): | ||||
|
MAX.SPEED(km/h) |
90 |
MAX.GRADEBILITY(°) |
30 |
|
|
MAX.BRAKINGDISTANCE(m) |
≤10 |
MIN.TURNING CIRCLE DIA.(m) |
16 |
|
|
NO. of LEAD SPRING(FRONT/REAR) |
8/10+8,7/9+6 |
AXES |
2 |
|
