SINOTRUK HOWO Chassis 9cbm Cement Mixer Truck for Sale
- China main port
- T/T
You May Like
-
SINOTRUK Heavy Duty Truck HOWO Concrete Mixer Truck for Sale ZZ1257N3641 (Strong Body & Big Power Concrete Mixer Truck for Sale)
-
Sinotruk Howo Concrete Machine Mixer Heavy Duty Truck Cargo Truck for Sale
-
Sinotruk Hohan 6x4 Light Diesel Concrete Mixer Truck(LM3246C1)
-
Sinotruk Hohan 6x4 Light Diesel Concrete Mixer Truck(LM3646C1)
-
Sinotruk Hohan 6x4 Light Diesel Concrete Mixer Truck(LM3846C1)
-
Sinotruk Hohan 6x4 Light Diesel Concrete Mixer Truck(LM4146C1)
Product Details
| Condition | New | Transmission Type | Manual | |
| Emission Standard | Euro 2 | Fuel Type | Diesel | |
| Dimensions (L x W x H) (mm) | 9125mm*2495mm*3790mm | Gross Vehicle Weight | 25000 | |
| Place of Origin | Shandong, China | Brand Name | SINOTRUK | |
| Model Number | ZZ1257N3641W |
Product Description
MAIN DESCRIPTION | |||
Overall Dimensions | 9125mm*2495mm*3790mm(L*W*H) | ||
Tare Weight | 13870kg | Payload | 22500kg |
Front Overhang | 1500mm | Rear Overhang | 2650mm |
Wheelbase | 3625mm+1350mm | Track (F/R) | 2022mm/1830mm |
CHASSIS | |||
Chassis Brand | SINOTRUK HOWO | ||
Chassis Model | ZZ1257N3641W, driving type 6x4 | ||
Cab | HW76, left hand drive, air-conditioner, one sleeper | ||
Engine | SINOTRUK WD615.69, 336hp, Euro II emission standard, 4-stroke direct injection diesel engine, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling, displacement 9.726L | ||
Transmission | HW15710, No. of speeds: 10 forward & 2 reverse | ||
Steering | German ZF8098, turning system pressure 18MPa | ||
Rear Axle | HC16 tandem axle, rated load 2x13ton, ratio 5.73 | ||
Wheels and tires | Rim 8.5-20; tire 12.00-20, 10 units; Spare wheel carrier: with one spare wheel | ||
Brakes | Service brake: Dual circuit pneumatic brake; Parking brake: Spring energy, compressed air operating on rear wheels; Auxiliary brake: Engine exhaust brake | ||
MIXING SYSTEM | |||
Mixing Volume | 9cbm | ||
Water Tank Volume | 440L | ||
Hydraulic Pump | Brand: ARK, Italy | ||
Motor | Brand: ARK, Italy | ||
Speed Reducer | Brand: TOPUNION, Italy | ||
Mixing Drum | Body steel plate thickness 6mm, Front end thickness 8mm. | ||
Jinan Sinoauto Heavy Duty Truck Sales co., Ltd of China is 4s shop which is authorized by China National Heavy Duty Truck Group Co., Ltd (CNHTC) in Shandong Province. It was founded in 2003, located in Jinan which is the famous production base of heavy duty truck of China. The 4 main functions of our company are heavy duty truck sale, spare part supply, information feedback, and after-sales service.
The team of our company can provide heavy duty trucks meeting the requirement of customers at the best price. We have many years of experience in supplying trucks, strict quality management, fast and convenient channel of goods delivery, strict examination in quality and quantity of products, professional box packing, professional and reliable loading goods in containers, on-time delivery and competitive price.
Products of our company are sold all over China, and are exported to more than ten countries and regions, such as Russia, Ukraine, Kazakhstan, Iran, Algeria, Nigeria, Africa, and Latin America. In a control of price and quality, our products are highly appreciated in these markets.
