Sino-Telecom 10G Optical Network Unit for CWDM/DWDM
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
Sino-Telecom
Model Number:
OEO6500-10G
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Sino-Telecom 100G Semiconductor Optical Amplifier / SOANegotiableMOQ: 1 Piece -
Sino-Telecom 40G Semiconductor Optical AmplifierNegotiableMOQ: 1 Piece
-
Sino-Telecom Erbium Doped Fiber Amplifier Optical Booster Amplifier /EDFANegotiableMOQ: 1 Piece
-
Sino-Telecom High-performance MUX/DEMUX for Dual Fiber Optical TransmissionNegotiableMOQ: 1 Piece
-
Sino-Telecom C Band 40 Channel DWDM Multiplexer and DemultiplexerNegotiableMOQ: 1 Piece
Place of Origin
Shanghai, China
Brand Name
Sino-Telecom
Model Number
OEO6500-10G
Overview
OEO6500-10G is an optical fiber link wavelength converter (fiber amplifier). It regenerates optical signals in the principle of optical-electrical-optical to realize the amplification and wavelength conversion of optical signals. Wavelength division multiplexing can be realized by using C/DWDM multiplexer/de-multiplexer, which especially applies to optical transport systems up to 10G SDH/SONET, Ethernet etc. It provides rapid and cost-efficient solutions to regeneration of optical signals as well as the transmission of rare fiber resources.
Features
- It supports a maximum port rate of 10Gb/s;
- The wavelength of C-Band, which supports DWDM wavelengths in compliance with ITU-T standards;
- It can be operated and controlled independently;
- It supports automatic loopback test;
- It supports 3R function. For neighboring ports, the way for data transmission can be set;
- It supports CDR function, which can optimize output.
Performance Specification
| Parameter | Module Type:10Gbps | |||
| Transimission Distance (km) | ~ 0.3 | ~10 | ~40 | ~80 |
| Laser Type | VCSEL | DML | EML | EML |
| Center Wavelength (nm) | 840~860 | 1290~1330 | 1530~1565 | 1530 ~ 1565 |
| Maximum Spectral Width (nm) | 1 | 1 | 1 | 1 |
| Side Mode Suppression Ratio (dB) | - | 30 | 30 | 30 |
| Average Output Power (dBm) | -7 ~ -1 | -6 ~ -1 | -1 ~ 2 | 0 ~ 4 |
| Extinction Ratio (dB) | > 3 | > 6 | > 8.2 | > 9 |
| Receive Type | PIN | PIN | PIN | APD |
| Minimum Load (dBm) | -3 | 0 | -9 | -9 |
| Receive Sensitivity (dBm) | < -10 | < -16 | < -16 | <-24 |
| Maximum Dispersion Tolerance (ps/nm) | n.a. | 35 | 800 | 1600 |
| Optical Path Penalty (dB) | 1 | 1 | 1 | 2 |
| Maximum Return Loss (dB) | -27 | -27 | -27 | -27 |
