Help CenterRound Copper-coated Carbon Electrodes
Related Products
Specifications
Round copper-coated carbon electrodes1.Made of high graphite
2.High quality,high purity
3.Rock bottom price,speedy delivery
Round copper-coated carbon electrodes
Shanghai Bochuan Silicon Carbon Rod Manufacturing Co., Ltd. is a company specializes in designing,developing,producing and marketing all types of carbon rods.Carbon rods made by Bo chuan company include DC copper coated jointed,flat and pointed gouging rods.Bochuan has advanced equipment and establishes a reliable quality-control system.
This product is based on graphite,felt by asphalted and modeled with thermal extruding mechanic and thermal plates
Product usage:The series of products have a widely use on shipbuilding,boiler pressure vessel making,casting,steel,storage cell in light mechanic and chemical makings.
Product capability:This product is used for incise,dig,driller,weldin.It is available for mild steel,cast steel,stainless steel,pure steel and other metals.
Product advantage:This product is easy to operate,having widely application scales,good effects and economical.
Instructions:
- The electrodes must keep in dry environment;if it is affected with damp must be drying before use.
- When using for the direct current,the electrodes link to the anode,and task to the cathode.
- Keeping steady of working air pressure 0.5-0.6Mpa.
- The arc between electrodes and task is 3mm,the electrodes come out clamp about 100mm.
- The electrodes and task must have a angle and dig throw the tangent.
- Keep aeration during use,operate accorde with the working limit.
Model |
(mm) |
(inches) |
Current ranger (A) |
|
3.2x305 |
1/8x12' |
130-180 |
|
4x305(355) |
5/32x12'(14') |
150-200 |
|
5x305(366) |
3/16x12'(14') |
200-250 |
|
6x305(355) |
15/64x12'(14') |
300-350 |
|
6.5x305(355) |
1/4x12'(14') |
320-370 |
|
7x355 |
9/32x14' |
350-400 |
|
8x305(355)(510) |
5/16x12'(14')(20') |
400-450 |
|
9x305(355) |
23/64x12'(14') |
450-500 |
|
10x305(355)(510) |
3/8x12'(14')(20') |
500-550 |
|
11x305(355)(510) |
7/16x12'(14')(20') |
600-650 |
|
12x305(355) |
15/32x12'(14') |
750-850 |
Attention:different needs of the customers can be supplied,such as the large current carbon rod with the surface of different lines.
