Specifications
Toilet Soap Stamping Machine / Soap Making Machine* Stamp 8-14 pieces / stoke
* Stamp 480 pieces / minute
Soap Machine
Toilet Soap Stamping Machine / Soap Making Machine: World lead double lane die sets vertical soap stamping which can stamp 8-14 pieces of soaps in one stoke, it can meet the needs of big scale production capacity requirement, completely unmanned operation style, it can connect with the whole soap production line operated by modular centralized control system. All the electrical componnents/control system adopts world top brand control system. More humanized machine design. extending to a brand new thought and reflection.
• Vertical printing, machinery high repeatability accuracy.
• The feeding system with vacuum sucker capable of turning down 90 degree.
• Low die turning 60 degree replaces previous 360 degree turning down to drawing the die.
• Germany FESTO pneumatic components of japanese imported SMC components.
Main Tech. Parameters:
Type |
XLD480 |
Working Speed |
Max 60 Times/Min |
Pieces Cut Each Time |
8*125g 10*60g |
Max. Weight Of The Soap |
175g |
Mould Cavity Temperature |
-2°C ~ -20°C |
Motor Power |
11kw |
Dimension (mm) |
2490*1810*2220 |
Weight |
5100kg |
