SC FC ST connector OPM / 3216 Fiber Optical Power Meter
1.Meters are interchangeable optical fiber connector, including SC, FC and ST connector.
2.Low battery indication
3.Working time up to 200h
4.Energy-saving design, 10 minutes Auto-off function
| Model | 3216A | 3216C |
| Calibrated(nm) | 850, 1300,1310,1490,1550,1625 | |
| Detector type | InGaAs | |
| Measurement Range(dBm) | -70~+6 | -50~+26 |
| Uncertainty (dB) | ±0.15(3.5%) | |
| linearity (dB) | ±0.02 | |
| Display resolution(dB) | 0.01 | |
| Frequency ID(Hz) | 270,330,1K,2K | |
| Wave ID(nm) | 1,310,149,015,501,620 | |
| Date storage capacity | 1000 | |
| Communication Port | USB | |
| Optical Connector type | FC,SC,ST interchangeable | |
| Alkaline battery | 3*AA,1.5V | |
| Power Supply Adaptor(V) | 8.4 | |
| Battery Operating time (h) | 200 | |
| Operation Temperature(℃) | -10~+60 | |
| Storage Temperature(℃) | -25~+70 | |
| Outline size(mm)/weight | 180*90*45(250g) | |
Features
1.USB communication port
2.Reference power level storage(Ref Setting)
3.Frequency identify and wavelength identify
4.Supply backlight button and intelligent control
5.1000 records storage or download via USB cable
6.Energy-saving design, 10 minutes Auto-off function
7.Supply backlight button and intelligent control(the light intensity can be adjusted according to ambient light, which greatly reduced power consumption)
Applications
1.Maintenance CATV&Telecom
2.Test Lab of Fiber Optic
3.Fiber Optic Measurements
4.Optical fiber sensors research
