Ring Die Pellet Mill Feed

Ring Die Pellet Mill Feed photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
China
Brand Name:
Ailence
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin China
Brand Name Ailence
Model Number SZLH25
Type Other, granulator machine
Voltage 380V
Power(W) 22kw
Warranty 12months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

ring die pellet mill feed
high efficiency
Full stainless steel feeder
SKF(NSK) bearings
NAK oil seal

                           Ring die pellet mill feed



Introduction of Ring die pellet mill feed

      Ring die pellet mill feed  Description: fuel particles machine using sawdust, crop straw (corn stalks, large soybean straw, sorghum, cotton stalk, rape straw, peanut vine, sunflower stalk), rice husk, grass, shrubs, branches, wood truncated, bamboo shavings, bagasse and other raw materials, the use of the machine temperature extruded into pellets. Finished cylindrical. Also be made of spherical, granular shape, honeycomb shape. Bio ring die pellet mill structure and working principle:

1, the main drive adopts high-precision gear drive, the ring mold with advanced quick detachable hoop type, yield 20% higher than the belt drive about

2, machine transmission parts (including motor inside) with Swiss, ring die pellet machine sawdust Japanese high quality bearings ensure transmission efficiency, stability and low noise.

3, using international advanced level of German gun drill and vacuum furnace heat manufacturing process, from the processing of high-quality alloy steel ring mold, long life and smooth out the grain, high quality.

4, the international advanced level of power transmission couplings, sawdust fuel pellet machine has a novel structure, compact, safe, low noise, low failure performance. 5, high-performance permanent magnet devices. 6, stainless steel door and chute with scale line stretching cutter, the cutter easy to adjust, and reliable.



specification

main motor power
(KW)

capacity
(t/h)

The feeding motor power (KW)

Motor power conditioning device
(KW)



Ring membrane diameter


(mm)

granule size
(mm)

SZLH25

22

1

0.75+0.55

2.2

250

φ6-10

SZLH32

37

1-1.5

0.75+0.55

2.2

320

φ6-10

SZLH35

55

1.5-2

0.75+0.75

2.2

350

φ6-10

SZLH40

75

2-2.5

1.5+0.75

2.2

400

φ6-10

SZLH42

90

2.5-3

1.5+0.75

5.5

420

φ6-10

SZLH508

132/160

3.0-5

1.5+0.75

7.5

508

φ6-10





Ring die pellet mill feed





Ring die pellet mill feed
