Oil well drilling Elevator Link
- 1000 Ton / Tons per Month
- China Main Port
- T/T L/C D/P D/A Credit Card PayPal
- API-7-1 Standard single cone drill bit
- 6 7 11 12 degree Diameter 32mm Taper Knock off drill bit
- Oil Well Api Oilfield Fishing Tool Overshot Grapple Assembly/Oil Well Magnetic Fishing Head/Cable Righting Fishing Head
- Drop Shipping API Oilfield Releasing Overshot 4 11/16" Oil Fishing Tools LT119
- API compliant fishing tool overshot for oil field downhole work
- Oil Well fishing tool sucker rod overshot/circulating overshots
Product Details
Place of Origin: | China | Brand Name: | SENWELL | Model Number: | sw038 |
Type: | Other, Elevator Link | Machine Type: | Drilling Equipment | Certification: | API |
Material: | High Manganese Steel | Processing Type: | Forging | Use: | Well Drilling |
Product Description
Elevator Link
Elevators links are suitable for hanging pipes in the operation of well drilling or repairing. According to the structures, they have two forms: Type DH & Type SH
Technical specification and parameters for DH type single arm elevator link | ||||||||||||
Type | Connecting sizes between elevator link lower ears and elevators(mm) | Connecting sizes between elevator link upper ears and drilling hooks(mm) | Length | Rated Cap. per Set | ||||||||
r1≤ | R1≥ | l1≥ | l2≥ | l3≥ | r≤ | R2≥ | l4≤ | l5≥ | l6≥ | (mm) | KN(t) | |
DH360 | 20 | 51 | 20 | 100 | 150 | 22 | 38 | 60 | 120 | 180 | 1200 | 360 (40) |
DH585 | 22 | 51 | 20 | 100 | 150 | 22 | 64 | 70 | 120 | 180 | 1100 | 585 (65) |
DH900 | 22 | 51 | 20 | 100 | 150 | 29 | 64 | 80 | 140 | 190 | 1500 | 900 (100) |
DH1350 | 24 | 51 | 25 | 100 | 150 | 29 | 64 | 100 | 140 | 210 | 1800 | 1350 (150) |
DH2250 | 31 | 70 | 30 | 140 | 200 | 35 | 102 | 140 | 200 | 250 | 2700 | 2250 (250) |
DH3150 | 37 | 70 | 35 | 140 | 200 | 35 | 102 | 140 | 200 | 250 | 3300 | 3150 (350) |
DH4500 | 48 | 83 | 50 | 170 | 250 | 48 | 121 | 160 | 240 | 300 | 3600 | 4500 (500) |
DH6750 | 57 | 127 | 50 | 190 | 318 | 63 | 127 | 190 | 262 | 305 | 3660 | 6750 (750) |
Length Dimensions of recommendation. It can be changed if necessary. |
SENWELL's main products cover 220 types and more than 1000 specifications presently. Our business covers non-magnetic products, drilling stem tools, fishing tools, jarring tools, coring tools, cementing tools, milling tools, well head tools, accessory tools, downhole tools, oil mining equipment, drill equipment, well control systems and pipes.
Today, with strong technology and profuse experience, SENWELL not only provides a comprehensive range of oilfield tools, but also provides tools for machinery industry and has decades of production experience. Main products are sand casting, investment casting, forging, centrifugal casting and machining equipment.
We have a great deal of outstanding and seasoned employees. Relying on advanced equipment and techniques, with the scientific management theory and spirit of "seriously dealing with matters relating to works", we have established long-term cooperative relationships with more than a hundred famous and large manufacturers in China. Our company creates a steady-going and reliable environment for our product research, development and sale.
We are based on the tenet of "providing consistent high quality products and the best services to meet the strict needs of our customers; to create value for our customers and provide our customers with a return on their investment" and the business philosophy of "people-oriented, customer first and reliability first". Our products have been successfully exported to Europe, America, the Middle East, South Africa and Southeast Asia. In the international market, we have acquired an excellent reputation among the clients.
We welcome new and old customers from all over the world to contact us for future business relationships and achieving mutual success! To benefit from our strong OEM/ODM capabilities and considerate services, contact us today. We believe you will be better with our support!
1.High quality products with favorable price at a right delivery.
2.Customized design
3.Warranty
