Help CenterStop Valve
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Pressure:
Other, 3.0Mpa
Power:
Manual
Payment & Shipping
Payment Methods:
Port of Shipment:
China main port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Standard or Nonstandard
Standard
Pressure
Other, 3.0Mpa
Power
Manual
Temperature of Media
Medium Temperature
Media
Oil
Place of Origin
China
Brand Name
Senwell
Specifications
Standard: API SPEC 6D standard.All stop valves adopt: 3.0Mpa air pressure testing.
All stop valves are suitable for al refrigerants including R22, R502, R1334a, R407C and air ,water, Steam, oil etc.
All stop valves are suitable for medium temperature: From -50 to 160.
Technical specifications and parameters for Stop Valve | ||||
Model |
The available of diameter |
The material of body |
Pressure |
The Dia. of link pipe |
J3/4 Stop valve |
4 |
HPb59-1 |
3.0MPa |
φ6.3 |
J3/6 Stop valve |
6 |
HPb59-1 |
3.0MPa |
φ8.3 |
J3/8 Stop valve |
8 |
HPb59-1 |
3.0MPa |
φ10.3 |
J3/10 Stop valve |
10 |
HPb59-1 |
3.0MPa |
φ12.3 |
J3/13 Stop valve |
13 |
HPb59-1 |
3.0MPa |
φ16.3 |
J3/16 Stop valve |
16 |
HPb59-1 |
3.0MPa |
φ19.3 |
J3/19 Stop valve |
19 |
HPb59-1 |
3.0MPa |
φ22.3 |
Send Inquiry to This Supplier
Business Type
Trading Company
Year Established
2010
Factory Size
Below 1,000 square meters
Total Employees
11 - 50 People
