API Annular BOP
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Senwell
Certification:
API
Payment & Shipping
Payment Methods:
Port of Shipment:
China main port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
China
Brand Name
Senwell
Certification
API
Material
Other, Steel
Processing Type
Forging
Use
Well Drilling
Specifications
Standard: API SPEC 16A.
Drift: 180mm
Rated working pressure: 35Mpa
Hydrostatic pressure strength: 52.5Mpa
Size: 750mm × 740mm
Weight: 1200kg
1,Packing element is spherical or tapered type with massive storage volume, low operation pressure and excellent sealing function;
2,Bonnet is hemispherical-shaped, so there is no stress concentration on bonnet whenever bearing the pressure.
3, Bonnet and body are connected by a wedge block, so the pressure is evenly distributed;
4, Packing element is interchangeable with similar overseas products;
5, Use observation hole to check the life span of the packing element;
6,Piston is set in low position to have a shorter moving distance; Use wear ring on piston.
