Home > Products > Recommend products > oilfield spherical forging stabilizer / API spherical forging stabilizer/ China high quality spherical stabilizer
oilfield spherical forging stabilizer / API spherical forging stabilizer/ China high quality spherical stabilizer
- 600 Piece / Pieces per Month
- China main port
- T/T Credit Card PayPal
- API 11AX SUCKER ROD PUMP
- Drilling Stabilizer
- oil well fishing services fishing tools washover pipe from chinese manufacturer
- Fine quality and wholesale API Sucker rod Stabilizer
- Integral Spiral Stabilizer.
- Lifting Caps/ Plugs downhole tools cross over subs drilling tools rig tools oilfield equipment
Product Details
Condition: | New | Application: | oil well drilling | Place of Origin: | China |
Brand Name: | sw | Model Number: | sw017 | Voltage: | 380V |
Power(W): | 11KW | Dimension(L*W*H): | Model | Weight: | varies according to size |
Features: | Forging | Certification: | API | Warranty: | 1 Year |
After-sales Service Provided: | No overseas service provided |
Product Description
Standard: API
Material: AISI 4145H, AISI 4145H Mod, AISI 4340, AISI 4140-4142 and Non-magnetic , etc
Feature: prevent hole inclination, improve drilling solution, improve drilling tools service life
Spherical Stabilizer
Spherical stabilizer is one of new type tools which is used in horizontal and directional well to prevent hole inclination, improve drilling solution, improve drilling tools service life and hole condition, cut off/scrape bore wall. Because of small size, simple structure, it is so applicable for horizontal and directional well. The guide inclined plane covered with polycrystalline compact and cutting edges covered with spherical tungsten carbide stud, during stabilizer contacts with roughed hole wall, can cut or scraped off raised or irregular well wall, therefore, the spherical stabilizers are widely used in various of drilling operation.
Detail Specification:
Technical specifications and parameters for Spherical Stabilizer | |||||||
O.D.(in) | Body OD on both ends(mm) | I.D.(mm) | Length (mm) | Thread on both ends(in) | |||
String type | Near bit type | ||||||
Top | Down | Top | Down | ||||
6~6 1/2 | 121 | 51 | 785 | 3 1/2 IF | 3 1/2 IF | 3 1/2 IF | 3 1/2 IF |
7~7 7/8 | 159 | 57 | 850 | 4 1/2 IF | 4 1/2 IF | 4 1/2 IF | 4 1/2 IF |
8~8 1/2 | 165 | 71 | 850 | 4 1/2 IF | 4 1/2 IF | 4 1/2 IF | 4 1/2 IF |
9~9 1/4 | 197 | 71 | 870 | 4 1/2 IF | 6 5/8 REG | 4 1/2 IF | 4 1/2 IF |
12~12 1/4 | 203 | 76 | 940 | 6 5/8 REG | 6 5/8 REG | 6 5/8 REG | 6 5/8 REG |
SENWELL's main products cover 220 types and more than 1000 specifications presently. Our business covers non-magnetic products, drilling stem tools, fishing tools, jarring tools, coring tools, cementing tools, milling tools, well head tools, accessory tools, downhole tools, oil mining equipment, drill equipment, well control systems and pipes.
Today, with strong technology and profuse experience, SENWELL not only provides a comprehensive range of oilfield tools, but also provides tools for machinery industry and has decades of production experience. Main products are sand casting, investment casting, forging, centrifugal casting and machining equipment.
We have a great deal of outstanding and seasoned employees. Relying on advanced equipment and techniques, with the scientific management theory and spirit of "seriously dealing with matters relating to works", we have established long-term cooperative relationships with more than a hundred famous and large manufacturers in China. Our company creates a steady-going and reliable environment for our product research, development and sale.
We are based on the tenet of "providing consistent high quality products and the best services to meet the strict needs of our customers; to create value for our customers and provide our customers with a return on their investment" and the business philosophy of "people-oriented, customer first and reliability first". Our products have been successfully exported to Europe, America, the Middle East, South Africa and Southeast Asia. In the international market, we have acquired an excellent reputation among the clients.
We welcome new and old customers from all over the world to contact us for future business relationships and achieving mutual success! To benefit from our strong OEM/ODM capabilities and considerate services, contact us today. We believe you will be better with our support!
1.High quality products with favorable price at a right delivery.
2.Customized design
3.Warranty
