AISI 4145H Heat Treated Alloy Steel 36" Oil Field Hole-opener With Nozzles

Name: AISI 4145H Heat Treated Alloy Steel 36" Oil Field Hole-opener With Nozzles
Brand: SENWELL
SKU: 123857401

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

China

Brand Name:

SENWELL

Machine Type:

Drilling Tool

Shaanxi Senwell Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China Main Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name SENWELL

Machine Type Drilling Tool

Certification API

Material Other, alloy steel

Processing Type Forging

Use Well Drilling

Specifications

Manufactured from AISI 4145H fully heat treated alloy steel and available with carbide-milled teeth and insert cutters.

The hole opener have three or six jet tubes with replaceable nozzles, so that jet streams quickly clean the enlarged hole.

The hole opener have three or six jet tubes with replaceable nozzles, so that jet streams quickly clean the enlarged hole.

Detail Specification:

Technical specifications and parameters for Hole Opener
Type	Hole open dia.(in)	Qty of cutter	Min. pilot hole(in)	Fishing neck dia.(in)	I.D(in)	Top Conn. (pin)	Bottom Conn.(box)	Overall length(in)
HO 311	12 1/4	3	8 1/2	8	1 1/2	6 5/8REG	6 5/8REG	55
HO 406	16	3	10	9 1/2	2 1/4	7 5/8REG	7 5/8REG	59
HO 444	17 1/2	3	10	9 1/2	2 1/4	7 5/8REG	7 5/8REG	59
HO 559	22	3	12 3/4	9 1/2	2 1/3	7 5/8REG	7 5/8REG	69
HO 584	23	3	12 3/4	8	3	6 5/8REG	6 5/8REG	69
HO 610	24	3	14	10	3	7 5/8REG	7 5/8REG	69
HO 660	26	3	17 1/2	10	3	7 5/8REG	7 5/8REG	69
HO 4-914	36	4	26	10	3 1/2	7 5/8REG	7 5/8REG	87
